DRILLS
makita.ca
106
STANDARD EQUIPMENT INCLUDES:
Magnetic Bit Holder 6.35-76 (784801-1), Locator (158876-0), 2 Ea. Phillips Insert Bits (784211-2)
Improved Lighter Gear Housing Makes More Easy Handling
And Maneuverability
• One touch locator for setting depth of drive
• Improved belt clip uses a metal body with protective plastic cover
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Variable Speed, Reversible, 0 - 4,000 RPM
1/4˝ Drywall Screwdriver
SPECIFICATIONS
Hex Shank
1/4˝
Hex
No Load Speed
0 - 4,000 RPM
AMPS (120V)
6.0 A
Overall Length
11-1/8˝ (284 mm)
Cord Length
8.2 ft. (2.5 m)
Net Weight
2.9 lbs. (1.3 kg)
FS4000
STANDARD EQUIPMENT INCLUDES:
Magnetic Socket Bit 5/16-65 (784804-5), Locator (450967-6)
Equipped With LED Job Light For Maximum Efficiency In
Low Light Conditions
• One touch locator for setting depth of drive
• Improved belt clip uses a metal body with protective plastic cover
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Variable Speed, Reversible, 0 - 2,500 RPM
1/4˝ Screwdriver
SPECIFICATIONS
Hex Shank
1/4˝
Hex
No Load Speed
0 - 2,500 RPM
AMPS (120V)
6.0 A
Overall Length
11˝ (280 mm)
Cord Length
8.2 ft. (2.5 m)
Net Weight
3.3 lbs. (1.5 kg)
FS2500
STANDARD EQUIPMENT INCLUDES:
Tool Only
Equipped With LED Job Light For Maximum Efficiency In
Low Light Conditions
• Quick change bit sleeve for fast and simple bit changes
• 6 stage clutch for precise control
• Improved belt clip uses a metal body with protective plastic cover
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Variable Speed, Reversible, 0 - 2,500 RPM
1/4˝ Screwdriver
SPECIFICATIONS
Hex Shank
1/4˝
Hex
No Load Speed
0 - 2,500 RPM
AMPS (120V)
6.0 A
Overall Length
11-1/8˝ (283 mm)
Cord Length
8.2 ft. (2.5 m)
Net Weight
3.7 lbs. (1.7 kg)
FS2701
STANDARD EQUIPMENT INCLUDES:
Side handle (122727-3), Plastic Carrying Case (824737-3)
Makita’s Most POWERFUL Impact Wrench
• 1˝ Square drive, 738 ft. lbs. (1,000 Nm)
• Side handle adjusts 360° for operator convenience at any angle
• Heavy duty front rubber bumper
• Rocker switch for easy one handed reversing
Reversible
1˝ Impact Wrench
SPECIFICATIONS
Square Drive
1˝ Square
Capacities:
Standard Bolt 1˝ - 1-3/16˝ (24 - 30 mm)
High Tensile Bolt 7/8˝ - 1˝ (22 - 24 mm)
Impacts Per Minute
1,500 IPM
No Load Speed
1,400 RPM
Fastening Torque 738 ft. lbs. (1,000 Nm)
AMPS (120V)
12.0 A
Overall Length
15.0˝ (382 mm)
Net Weight
19.0 lbs. (8.6 kg)
TW1000
Equipped with LED Job Light for Maximum Efficiency In Low Light Conditions
• One touch locator for setting depth of drive
• Equipped with Makita's ˝Silent Clutch˝ for improved performance and durability (FS6300 Only)
• Improved belt clip uses a metal body with protective plastic cover
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Variable Speed, Reversible
SPECIFICATIONS
Hex Shank
1/4˝ Hex
AMPS (120V)
6.0 A
Cord Length
8.2 ft. (2.5 m)
FS6300:
No Load Speed
0 - 6,000 RPM
Overall Length
11-1/2˝ (293 mm)
Net Weight
3.1 lbs. (1.4 kg)
FS4200:
No Load Speed
0 - 4,000 RPM
Overall Length
11-1/8˝ (284 mm)
Net Weight
2.9 lbs. (1.3 kg)
FS2200:
No Load Speed
0 - 2,500 RPM
Overall Length
11-7/8˝ (302 mm)
Net Weight
3.5 lbs. (1.6 kg
)
0 - 6,000 RPM
STANDARD EQUIPMENT INCLUDES:
Magnetic Bit Holder 6.35-76 (784801-1),
Locator (158876-0),
2 Ea. Phillips Insert Bits (784211-2)
FS6300
0 - 2,500 RPM
STANDARD EQUIPMENT INCLUDES:
Magnetic Socket Bit 6.35-76 (784801-1),
Locator (158876-0),
2 Ea. Phillips Insert Bits 2-25 (784211-2)
FS2200
0 - 4,000 RPM
FS4200
STANDARD EQUIPMENT INCLUDES:
Magnetic Bit Holder 6.35-76 (784801-1),
Locator (158876-0),
2 Ea. Phillips Insert Bits (784211-2)
FS6300, FS4200, FS2200
1/4˝ Drywall Screwdrivers
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
