OmniBohrer CONSTRUCTION DRILL BITS
• Suitable for use with Concrete, Tile, Brick, Slate, Limestone, Wood, Sandwich Materials,
Aluminum and Plastic
• Ideal for use in applications where a range of
materials are encountered
• Eliminates need to switch between bit types
• Features Tungsten Carbide tip for fast and efficient drilling
• Wide Flutes enable quick and efficient material extraction
Part No.
Diameter
Shank Useable Length Overall Length
D-36859
1/8"
1/8"
1-3/8"
3"
D-36865
5/32"
5/32"
1-5/8"
3-1/8"
D-36871
4-3/16"
6"
D-36887
3/16"
3/16"
1-3/4"
3-1/2"
D-36893
4-3/8"
6"
D-36902
1/4"
1/4"
2-3/16"
4"
D-36918
4-3/8"
6"
D-36924
5/16"
5/16"
2-7/16"
4-3/4"
D-36930
4-3/16"
6"
D-36946
3/8"
3/8"
4-3/16"
6"
D-36952
1/2"
3-5/8"
6"
D-37100 5 Pc Set (Incl. 1/8"x3", 3/16"x3-1/2", 1/4"x4", 5/16"x6", 3/8"x6")
ROTARY PERCUSSION HAMMER DRILL BITS
Diameter Shank Size Overall Length Usable Length Part No.
3/16"
3/16"
4"
2-1/2"
711120-A
1/4"
1/4"
4"
2-1/2"
711121-A
6"
4"
711122-A
13"
10"
711128-A
5/16"
5/16"
6"
4"
711123-A
3/8"
3/8"
6"
4"
711124-A
13"
10"
711129-A
1/2"
3/8"
6"
4"
711125-A
13"
10"
711130-A
5/8"
3/8"
6"
4"
711126-A
13"
10"
711131-A
3/4"
3/8"
6"
4"
711127-A
13"
10"
711132-A
• Suitable for use in medium and hard masonry (mortar, block and brick)
• Carbide-tipped for long life and maximum performance
• Wide flutes enable rapid dust removal
SDS-MAX DRILL BIT REMOVER
195871-9
Description
• Ideal for removing stuck SDS-MAX Drill Bits, Core
Bits and Core Cutters from concrete
• Use with 1/2" Square Drive Impact Wrench with
minimum Maximum Fastening Torque of
184 ft. lbs. (250 Nm)
• Requires Flat Head Pin
(included as Standard Equipment)
SDS-MAX DUST EXTRACTION ATTACHMENT
Part No.
Description
For Use
With Models
Includes
196074-8
• Ideal for use in dust
sensitive environments
• Can be operated in
both drilling and
demolition modes
• Can be used with Drill
Bits up to 22" length
or Demolition Bits up
to 24" length
HR4002
HR4010C
HR4011C
HR4510C
HR4511C
• Dust Extraction Attachment
• Side Handle
• Depth Gauge
• Dust Cover Cap (2 ea)
• Bellows (2 ea)
• Joint (2 ea)
196536-6
HR4013C
HR4013CV
ROTARY HAMMER DUST CUP
Rubber Dust Cap quickly attaches to SDS-PLUS Rotary Hammer Bits to prevent
dust and debris from falling on operator
Dust Cap Part No.
Bit Diameter
421342-3
1/4" - 9/16"
421664-1
15/32" - 5/8"
ROTARY HAMMER DUST BOOTS
• Dust Boot surrounds bit during overhead drilling applications
to prevent dust and debris from falling on operator
• Can also be used in horizontal drilling or demolition
applications to limit contamination of working environment
• Must be used with appropriate Grip Base Set
For Models
Dust Boot Part No. Grip Base Part No.
HR1830F
194580-7
194581-5
DHR202RFE / Z, DHR241RFE / F / Z
DHR263Z, DHR264Z, HR2470F, HR2475
194582-3
HR2811F
(No Grip Base
Required)
LXRH02Z, HR2611FT
195132-7
DHR242RFEV / RFE / Z, HR2611F, HR2621
195048-6
ROTARY & DEMOLITION HAMMER
CLEANING CLOTH
443122-7
Description
• Use for cleaning and maintaining Makita
rotary and demolition hammers
• Measures approximately 16" x 14"
ROTARY & DEMOLITION HAMMER BIT GREASE
194683-7
Description
• Use with SDS-PLUS and SDS-MAX drilling and
demolition bits
• Eliminates friction and maintains optimal performance,
bit and tool life
• Apply approximately 0.6 - 1.2 mL per bit
SDS-PLUS 1/2" DRILL CHUCKS
• For drilling applications only in wood or metal using round shank bits
• Quickly attaches to any SDS-PLUS Rotary Hammer
Part No.
Description
122574-2
1/2" Keyed Chuck
(Use with 1/2" Chuck Key 798341-3)
122823-7
1/2" Keyless Chuck
