Electric
Power Tools
makita.ca
99
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763098-5), Chuck Key (763434-5)
Multi Purpose Drill For Wood And Metal
• Lightweight 3.3 lbs. (1.5 kg) and well balanced for easy handling
• Heavy duty industrial drill chuck
• Double gear reduction for extra power
• Large recessed lock-on button
• Separate reversing switch
• All ball bearing construction for long tool life
• Variable speed for drilling in a wide variety of materials
Variable Speed, Reversible
3/8˝ Drill
SPECIFICATIONS
Capacities:
Steel
3/8˝ (10 mm)
Wood
13/16˝ (21 mm)
No Load Speed
0 - 1,200 RPM
AMPS (120V)
5.2 A
Overall Length
10-5/8˝ (264 mm)
Net Weight
3.3 lbs. (1.5 kg)
6402
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763136-3), Chuck Key (763403-6C)
Multi-Purpose Drill For Wood And Metal
• Separate reversing switch for ease of operation
• High power-to-weight ratio 3.1 lbs. (1.4 kg)
• Variable speed (0-1,200 RPM) for drilling in a wide variety of materials
• Double reduction gear design for extra torque
• Conveniently located lock-on-button for continuous use
• Industrial 3/8˝ chuck for accurate drilling
Variable Speed, Reversible
3/8˝ Drill
SPECIFICATIONS
Capacities:
Steel
3/8˝ (10 mm)
Wood
3/4˝ (18 mm)
No Load Speed
0 - 1,200 RPM
AMPS (120V)
3.5 A
Overall Length
9-1/2˝ (242 mm)
Net Weight
3.1 lbs. (1.4 kg)
6510LVR
Powerful 6.5 AMP Motor With Lower RPM For
Heavy Duty Continuous Use
• Industrial Aluminum Gear Housing for increased durability
• Industrial Strength 1/2˝ Keyed Chuck for durability
• Large, Conveniently Located Reverse Switch with Lock-On Button for operator convenience
during periods of prolonged use
• Heavy Duty Belt Clip for operator convenience
Variable Speed, Reversible
SPECIFICATIONS
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-3/8˝ (36 mm)
No Load Speed:
6303H
0 - 850 RPM
6302H
0 - 550 RPM
AMPS (120V)
6.5 A
Overall Length 11-1/4˝ (285 mm)
Net Weight
4.8 lbs. (2.2 kg)
0 - 850 RPM
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763078-1),
Chuck Key (763411-7A),
Side Handle (122593-8)
6303H
0 - 550 RPM
6302H
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763078-1),
Chuck Key (763411-7A),
Side Handle (122593-8)
6303H, 6302H
1/2˝ Drills
STANDARD EQUIPMENT INCLUDES:
Keyless Chuck (763132-1), Plastic Carrying Case (A82500-7)
General Purpose Entry Level Drill For Light Drilling
• Keyless chuck for fast and easy bit installation and removal
• Variable speed (0 - 2,500 RPM) for drilling in a wide variety of materials
• Low decibel rating (79 dB) for quieter operation
Variable Speed, Reversible
3/8˝ Drill
SPECIFICATIONS
Capacities:
Steel
3/8˝ (10 mm)
Wood
1˝ (25 mm)
No Load Speed
0 - 2,500 RPM
AMPS (120V)
4.9 A
Overall Length
10-1/4˝ (261 mm)
Net Weight
3.3 lbs. (1.5 kg)
6408K
STANDARD EQUIPMENT INCLUDES:
Keyless Drill Chuck (763180-0), Plastic Carrying Case (187043-0)
General Purpose Drill Featuring Compact And Lightweight Design
• All ball bearing construction for smooth and durable operation
• Variable Speed trigger for drilling in a wide variety of materials
• Powerful motor rated at 4.0 Amps with 450W Continuous Input
• Keyless Chuck for quick and easy bit installation and removal
• Forward/Reverse switch for easy switching between operating modes
• Lock-On Button for continuous operation
• Lanyard Loop for attachment of lanyard when working at heights
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Variable Speed, Reversible
3/8˝ Drill
SPECIFICATIONS
Capacities:
Steel
3/8˝ (10 mm)
Wood
1˝ (25.4 mm)
No Load Speed
0 - 3,400 RPM
AMPS (120V)
4.0 A
Overall Length
9-1/4˝ (234 mm)
Net Weight
3.3 lbs. (1.5 kg)
6413K
