METALWORKING
makita.ca
108
STANDARD EQUIPMENT INCLUDES:
1 Ea. 16˝Abrasive Wheel (A-90174), Socket Wrench (782210-8), Quick Vise (134549-9), 2Ea.Lock Off Button (411447-7)
AC/DC
• Quick release vice
• Lock-Off button prevents accidental start up
• Spark Guard for operators safety
• Externally accessible carbon brushes
Mitres 45° Left And Right
16˝ Portable Cut-Off Saw
SPECIFICATIONS
Blade Diameter
16˝ (405 mm)
Arbor
1˝ (25.4 mm)
No Load Speed
2,300 RPM
AMPS (120V)
13.0 A
Overall Length
24˝ (610 mm)
Net Weight
42.3 lbs. (19.2 kg)
2416S
STANDARD EQUIPMENT INCLUDES:
12˝ C.T.Blade 60T(A-90897), Socket Wrench (782210-8), 2 Ea.Lock Off Button (411478-6), Safety Goggles (192219-6)
Cold Cutting Metal Saw Uses Specialized TCT Metal Cutting Blade
For Precise Cutting Without Burring
• Quick Release Vice
• Lock-Off button to prevent accidental starting
• Spark Guard for operators safety
• Tool-less guide plate adjustments
• Cast aluminum base for lighter weight portability
• Externally accessible carbon brushes
Tool-Less Guide Plate Adjustment
For 0°- 45° Mitre Cuts
12˝ Portable Cut-Off Saw
SPECIFICATIONS
Blade Diameter
12˝ (305 mm)
Arbor
1˝ (25.4 mm)
No Load Speed
1,300 RPM
AMPS (120V)
15.0 A
Overall Length
20-1/4˝ (516 mm)
Net Weight
42.5 lbs. (19.3 kg)
LC1230
STANDARD EQUIPMENT INCLUDES:
Phillips Bit 2-50(784244-7)
Multi-Purpose, Lightweight Impact Driver Can Be Used
For Any Light Fastening Applications
• Compact design and light weight (Only 8-5/8˝ and 2.1 lbs)
• Compact bit sleeve
• Easy to operate forward and reverse change lever
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Variable Speed, Reversible
1/4˝ Impact Driver
SPECIFICATIONS
Hex Shank
1/4˝ Hex
Impacts Per Minutes
0 - 3200 IPM
No Load Speed
0 - 3600 RPM
Maximum Torque 885 in.lbs (100 N.m)
Capacities:
Machine Screw M4 - M8 (5/32˝ - 5/16˝)
Standard Bolt M5 - M14 (3/16˝ - 9/16˝)
High Tensile BoltM5 - M10 (3/16˝ - 3/8˝)
AMP (120V)
1.7 A
Overall Length
8-5/8˝ (218 mm)
Net Weight
2.1 lbs. (1.0 kg)
TD0100
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
IMPACT WRENCH ACCESSORIES
Description
Application
For Model(s)
Part No.
1/2" Square Drive
Impact Extension
For work in
narrow areas
where socket will
not reach
DTW251RFE / F / FX1 /
XRFE / Z / ZX1
DTW253RFE / F / Z
DTW450RFE / F /
Z / FX1 / XRFE / Z / XZ
TW0350
6905B, 6953
134874-8
1/2" Square Drive
Bit Adapter
For driving
machine screws
134873-0
1/2" Square Drive
Large Universal Joint
For use in areas
where tool
cannot be held
in line with bolt
or nut
134877-2
1/2" Square Drive
Small Universal Joint
134878-0
3/4" Square Drive
Impact Extension
For work in
narrow areas
where socket will
not reach
6906
134997-2
3/4" Square Drive
Bit Adapter
For driving
machine screws
134998-0
IMPACT SOCKET SETS
Type
Square
Drive Size Qty / Pk
Sizes
Finish
Part No.
Imperial
(SAE)
1/4"
8 Pcs
3/16", 1/4", 5/16",
11/32", 3/8", 7/16",
1/2" & 1/4"
Socket Adapter
Black
Oxide
785501-A-A
3/8"
9 Pcs
5/16", 3/8", 7/16",
1/2", 9/16", 5/8",
11/16", 3/4" & 3/8"
Socket Adapter
785508-A-A
