DRILLS
makita.ca
100
STANDARD EQUIPMENT INCLUDES:
Key Holder (418198-3), Chuck Key (763418-3), 1/4" Drill Chuck (763077-3)
Designed For High Drilling Efficiency
• Variable speed dial enables operator to adjust drilling speed based on materials or application
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
1/4˝ Drill
SPECIFICATIONS
Capacities:
Steel
1/4˝ (6.5 mm)
Wood
9/16˝ (15 mm)
AMPS (120V)
3.2 A
No Load Speed
0 - 4,000 RPM
Overall Length
8-1/4˝ (209 mm)
Net Weight
2.2 lbs (1.0 kg)
DP2010
DA4031
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (193520-2), Chuck key (763434-5), Grip 27 (273654-8), Hex Wrench 6 (783204-6), Front Grip (417665-5)
Plastic Carrying Case (824647-4)
Designed For Efficient Drilling Between Studs & Joists
• Ergonomic design ensures best performance while drilling in frame construction, plumbing
and electrical work
• Tool-free rear handle swivels 90° Left or Right for easy drilling
• Built in torque limiter stops drill bit rotation when bit hits reinforcements
Torque Limiter
1/2˝ Angle Drill
SPECIFICATIONS
Drilling capacities:
Wood:
Auger-bit
1-1/2˝ (38 mm)
Self-feed bit
4 -5/8˝ (118 mm)
Hole saw
6˝ (152 mm)
Steel:
Twist bit
1/2˝ (13 mm)
AMPS (120V)
10.0 A
No Load Speed:
Low
300 RPM
High
1,200 RPM
Overall Length
18-1/4˝ (462 mm)
Net Weight
13.9 lbs. (6.3 kg)
5-1/2˝
DA6301
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763062-6), Chuck Key S13 (763432-9), Grip (Side handle)(273476-6), Grip (Top handle)(273628-9)
Steel Carrying Case (181791-3)
For Heavy Duty Drilling With Torque Limiter
• Double reduction gearing for maximum power
• Ball bearing construction for longer life
• Built in torque limiter stops drill bit rotation when bit hits reinforcements
• Rocker Switch for easy one handed operation
• Large side handle for controlled handling
2 Speed, Reversible, Torque Limiter
1/2˝ Angle Drill
SPECIFICATIONS
Drilling Capacities:
Steel
1/2˝ (13 mm)
Wood
1-3/8˝ ( 36 mm)
AMPS (120V)
7.5 A
No Load Speed:
Low
300 RPM
High
1,200 RPM
Overall Length
16-1/8˝ (410 mm)
Net Weight
10.4 lbs. (4.7 kg)
7-1/8˝
DA4000LR
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (193319-5), Chuck Key (763434-5), Side Grip (For tool barrel)(152892-4), GripAssy (Angle)(122646-3),
Hex Wrench 5 (783216-9), Plastic Carrying Case (824646-6)
Angle Attachment Rotates 360° To Drill In Any Position
• Durable / Dust-Proof Switch featuring large trigger for comfortable operation
• Industrial metal gear housing for durability and long tool life
• Angle attachment may be removed and drill used as a straight drill
Variable 2-Speed, Reversible
1/2˝ Angle Drill
SPECIFICATIONS
Drilling capacities:
Wood:
Low
High
Auger-bit
1-1/2˝ (38 mm)
1-1/2˝ (38 mm)
Self-feed bit
4-5/8˝ (118 mm)
2-9/16˝ (65 mm)
Hole saw
6˝ (152 mm)
4-1/2˝ (114 mm)
Steel:
Twist Bit
1/2˝ (13 mm)
AMPS (120V)
7.5 A
No Load Speed:
Low
0 - 400 RPM
High
0 - 900 RPM
Overall Length
16-1/4˝ (413 mm)
Net Weight
8.8 lbs. (4.0 kg)
5-1/2˝
DA3010F
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763174-5), Chuck Key (763415-9), Grip (153489-2)
Built-In LED Job Light For Excellent Work Efficiency
• Industrial metal gear housing for durability and long tool life
• Reduced head height (2-5/8˝) for working in limited space
• Ball bearing construction for longer motor life
• Paddle switch with speed limiting dial
• Compact (10-5/8˝ length) design for easy use when working between framing studs or any other
close quarter application
Variable Speed, Built-In LED Job Light
3/8˝ Angle Drill
SPECIFICATIONS
Capacities:
Wood
1˝ (25 mm)
Steel
3/8˝ (10 mm)
No Load Speed
0 - 2,400 RPM
AMPS (120V)
4.0 A
Overall Length
10-5/8˝ (270 mm)
Net Weight
3.5 lbs. (1.6 kg)
2-5/8˝
30" EXTENSION ATTACHMENT
193317-9
Description
For Model
• Operates at up to 600 RPM with No Power Loss
• Extends reach of drill up to 30"
DA4000LR
For Model
DA4000LR
Only
