METALWORKING
makita.ca
114
STANDARD EQUIPMENT INCLUDES:
VibrationProofGrip(194514-0),LockNutWrench28(782424-9),ToollessWheelCoverAssyF/5"(135108-2),5"DepressedCentreWheel(741407-B),
InnerFlange45(224399-1),LockNut5/8-45(224568-4)
Trigger Switch with Lock-On Button (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and
operator protection
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Anti-Restart feature prevents accidental start up of tool if switch is locked in the on position
• LED Light indicates active power supply and activation of anti-restart feature
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
“SJS” Technology, Electronic Current
Limiter, Soft Start, Constant Speed Control
5˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding/Sanding
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
12.5 A
Overall Length
15-3/8˝ (390 mm)
Net Weight
6.4 lbs. (2.9 kg)
GA5020C
STANDARD EQUIPMENT INCLUDES:
SideHandle(153504-2),LockNutWrench(782424-9),ToollessWheelCover(135108-2),5˝DepressedCentreWheel(741407-B),Inner Flange
(224399-1), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Two-Stage Safety Trigger Switch (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and
operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
“SJS” Technology, Electric Brake
5˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
10.5 A
Overall Length
14˝ (356 mm)
Net Weight
6.0 lbs. (2.7 kg)
GA5020Y
STANDARD EQUIPMENT INCLUDES:
Side Handle (153504-2), Lock Nut Wrench (782424-9),Toolless Wheel Cover (135108-2), 5” Depressed Centre Wheel (741407-B),
Inner Flange (224399-1), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Trigger Switch with No Lock-On Button (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of too
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
“SJS” Technology, Electric Brake
5˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding
Wheel 5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
10.5 A
Overall Length
14˝ (356 mm)
Net Weight
6.0 lbs. (2.7 kg)
GA5020
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Centre Wheel (741407-B), Wheel Guard (125097-9),
Side Handle (152492-0), Inner Flange (224378-9), Lock Nut (224568-4), Lock Nut Wrench (782412-6)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened poweder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every
90° for optimal positioning
• Removable side handle can be mounted on
left or right side of tool
5˝ Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
12.5 A
Overall Length
15-3/8˝ (391 mm)
Net Weight
7.7 lbs. (3.5 kg)
9015DB
Has AC/DC Paddle Switch
9015DBZ
Has AC/DC Trigger Switch (Shown)
STANDARD EQUIPMENT INCLUDES:
GA5010:
Side Handle (153504-2), Lock Nut Wrench (782424-9),Toolless Wheel CoverAssy (135108-2), 5˝ Depressed Centre Wheel
(741407-B), Inner Flange 45 (224399-1), Lock Nut 5/8-45 (224568-4)
GA5010Z:
Side Handle (153504-2), Lock Nut Wrench (782424-9),Tool-less Wheel CoverAssy (135108-2), 5˝ Depressed Centre Wheel
(741407-B), Inner Flange 45 (224399-1), Lock Nut 5/8-45 (224568-4)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or
right side of tool
• Ergonomic soft rubber grip design for vibration
absorption and comfortable operation
5˝ Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
10.5 A
Overall Length
14˝ (356 mm)
Net Weight
5.7 lbs. (2.6 kg)
Paddle Switch
with Lock-On Button
(AC/DC)
9015DB
Trigger Switch
with Lock-On Button
(AC/DC)
9015DBZ
Trigger Switch with
Lock-On
Button (AC/DC)
GA5010
Trigger Switch with
No Lock-On
Button (AC/DC)
GA5010Z
STANDARD EQUIPMENT INCLUDES:
1 Ea. of 6˝Thin Kerf Cut-Off Wheel (724117A25), Lock Nut Wrench (782412- 6), Side Handle (153489-2), Lock Nut (224574-9),
Inner Flange (224390-9), Wheel Guard (165486-6)
Thumb Switch with Lock-On (AC)
• "SJS" (Super Joint System) prevents kickback during wheel lock up for optimal tool
and operator protection
• Labyrinth construction seals motor and bearings from contamination
• Electronic current limiter protects motor from accidental overload
• Thumb switch conveniently located for operator comfort
• Removable side handle can be mounted on left or right side of tool
• Tool-less wheel guard adjustment
“SJS” Technology, Variable Speed,
Electronic Current Limiter
6˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6˝ (150 mm)
Sanding Disc
6˝ (150 mm)
Diamond Wheel
6˝ (150 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
No Load Speed
4,000 - 9,000 RPM
AMPS (120V)
12.0 A
Spindle Thread
5/8˝ - 11 UNC
Overall Length
11-3/4˝ (299 mm)
Net Weight
5.3 lbs. (2.4 kg)
9566CV
