Electric
Power Tools
makita.ca
111
STANDARD EQUIPMENT INCLUDES:
Side Handle (152492-0)
Trigger Switch with Lock-On Button (AC/DC)
• Heavy duty motor design ideal for continuous operation
• Removable side handle can be mounted on left or right side of tool
• Accepts 7˝ or 9˝ wheels when used with proper guards
9˝ / 7˝ Angle Grinder / Sander
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7˝ or 9˝
(180 mm or 230 mm)
Sanding Disc
7˝ (180 mm)
Wire Cup Brush
6˝ (150 mm)
Spindle Thread
5/8˝-11 UNC
No Load Speed
6,000 RPM
AMPS (120V)
15.0 A
Overall Length
16-1/4˝ (412 mm)
Net Weight
12.2 lbs. (5.5 kg)
GA7911
• Heavy duty torque limiter prevents damage to internal gearing and prevents operator from
experiencing a surge of torque during wheel lock up
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Includes rear vent ˝Dust Cover Assembly˝ for added protection against dust and debris (GA9031Y Only)
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rear handle swivels 180
°
to adjust to the most comfortable grinding position
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
9˝ (230 mm)
Sanding Disc
7˝ (180 mm)
Wire Cup Brush
4-3/8˝ (110 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
6,600 RPM
AMPS (120V)
15.0 A
Overall Length
19-7/8˝ (504 mm)
Net Weight
14.3 lbs. (6.5 kg)
STANDARD EQUIPMENT INCLUDES:
Vibration Proof Grip (194543-3),
Lock Nut Wrench 28 (782412-6),
Tool-less Wheel CoverAssembly (122768-9),
Inner Flange 89 (224317-9), Lock Nut 5/8-45 (224568-4)
GA9031
Trigger Switch with
Lock-On Button
(AC/DC)
GA9031, GA9031Y
9˝ Angle Grinders
STANDARD EQUIPMENT INCLUDES:
Vibration Proof Grip (162264-5), Dust CoverAttachment Set (194289-1),
Lock Nut Wrench 28 (782412-6),Tool-less Wheel CoverAssembly (122768-9),
Inner Flange 89 (224317-9), Lock Nut 5/8-45 (224568-4)
GA9031Y
Two Stage Safety
Trigger Switch
(AC/DC)
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
BAND SAW ACCESSORIES
194026-3
191897-9
Band Saw Stand
Band Saw Blade
Cutting Wax
Description
• Converts Portable Band Saw to
Stationary Band Saw
• Fast and Easy Installation
• Cast Iron Construction
• Reduces Heat Builup
• Increases Cutting Performance
of Band Saw Blades
For Models
DPB180RFE / F / Z, 2107FK
DPB180RFE / F / Z, DPB181RFE / Z, 2107FK
Built In Work Light For
Excellent Efficiency
• Dual bearing blade guides for cutting
• Blade tightening lever for fast and easy blade installation
• Accepts standard 44-7/8˝ x 1/2˝ blade
• Lightweight design
• Electronic speed control dial
• Very rigid design minimizes tool flex while cutting
• Fluorescent Job Light with independent On / Off switch
SPECIFICATIONS
Cutting Capacities:
Round Work Piece Diameter
4-3/4˝ (120 mm)
Square Work Piece 4-3/4˝ x 4-3/4˝ (120 mm x 120 mm)
Blade Speed
197 - 354 ft./min. (1.0 - 1.8 m/sec.)
AMPS (120V)
6.5 A
Overall Length
20˝ (508 mm)
Net Weight
13.2 lbs. (6.0 kg)
2107FK
STANDARD EQUIPMENT INCLUDES:
Joint (P-80014), 2 Ea. Hex Wrench (783204-6), Nylon Brush Wheel 120-100 (794379-6)
Mitres 45° Left And Right
BAND SAW BLADES
Blade Length Blade Thickness Teeth per Inch (TPI) Blade Material
Application
For Model(s)
Qty / Pk.
Part No.
32-7/8"
1/2"
14 TPI
Bi-Metal
Plastics, Non-Ferrous Metals, Mild Steel, Cast Steel,
Cast Iron, Hard Steel & Stainless Steel
DPB181RFE / Z
5 / Pk
B-40543
18 TPI
B-40559
44-7/8"
10 TPI
Bi-Metal
Plastics, Non-Ferrous Metals, Mild Steel,
Cast Steel, Cast Iron, Hard Steel &
Stainless Steel
DPB180RFE / F / Z
2107FK
1 / Pk
792557-B
14 TPI
792557-A
18 TPI
792556-A
24 TPI
792555-A
6 TPI
Carbon Steel
Plastics, Non-Ferrous Metals, Mild Steel,
Cast Steel, Cast Iron
3 / Pk
792567-9
14 TPI
792560-A
18 TPI
792559-A
24 TPI
792558-A
Portable Band Saw
STANDARD EQUIPMENT INCLUDES:
Carbon Steel Band Saw Blade (792559-A), Hex Wrench (783202-0), Plastic Carrying Case (824728-4)
