METALWORKING
makita.ca
116
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (741407-B), Wheel Cover (125274-3), Lock Nut Wrench (782424-9), Inner Flange (224399-1),
Lock Nut (224568-4), Side Handle (153489-2)
Thumb Switch with Lock-On (AC/DC)
• Labyrinth construction seals motor and bearings from contamination
• Thumb switch conveniently located for operator comfort
• Removable side handle can be mounted on left or right side of tool
5˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
7.5 A
Overall Length
10-5/8˝ (271 mm)
Net Weight
4.6 lbs. (2.1 kg)
9558NB
STANDARD EQUIPMENT INCLUDES:
4-1/2˝ Depressed Centre Wheel (D-20781), Side Handle(153489-2), Lock Nut Wrench 28 (782424-9), Wheel Cover (135107-4),
Inner Flange 45 (224399-1), Lock Nut 5/8-45 (224568-4)
Two Stage Safety Paddle Switch (AC)
• “SJS” Technology prevents kickback if wheel jams protecting both the operator and tool
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left or right side of tool
• Rotatable gear housing can be positioned at every 90°
• Advanced dust-proof construction
“SJS” Technology, Variable Speed,
Electronic Current Limiter
4-1/2˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4-1/2˝ (115 mm)
Sanding Disc
4-1/2˝ (115 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
2,800 - 10,500 RPM
AMPS (120V)
13.0 A
Overall Length
12-1/8˝ (307 mm)
Net Weight
5.3 lbs. (2.4 kg)
9564PCV
STANDARD EQUIPMENT INCLUDES:
5 ˝ Depressed Centre Wheel (741407-B), Lock Nut Wrench (782424-9), Lock Nut (224568-4), Inner Flange (224399-1) , Wheel Cover
Assembly (122887-1), Side Handle (153504-2), Plastic carrying Case (824736-5)
Thumb Swith with Lock-On (AC)
• Labyrinth construction seals motor and bearings from contamination
• “Zig - Zag” varnish on armature and powder coating on field to protect motor from abrasion
• Engineered for durability – double protection against dust, high quality motor and machined gears
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
• Slim housing design for easy handling and maneuverability
• Thumb switch conveniently located for operator comfort
5˝ Angle Grinder With Slim Motor Housing
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90mm)
Spindle Thread
5/8˝ - 11UNC
No Load Speed
11,000 RPM
AMPS (120V)
6.0 A
Overall Length
10-1/2˝ ( 266 mm)
Net Weight
4.0 lbs. (1.8 kg)
GA5030K
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Center Wheel (741407-B), Wheel Cover (125268-8), Lock Nut Wrench (782424-9), Inner Flange (224399-1),
Lock Nut (224568-4), Side Handle (153489-2)
Two Stage Safety Paddle Switch (AC/DC)
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left hand
• Removable side handle can be mounted on left or right side of tool
5˝ Angle Grinder
SPECIFICATIONS
Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
7.5 A
Overall Length
10-3/4˝ (273 mm)
Net Weight
4.6 lbs. (2.1 kg)
9558PB
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Thumb Switch with Lock-On (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electronic Current Limiter prevents motor burnout due to overloading
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Re-Designed Gear Housing for enhanced shaft lock durability
• Labyrinth Construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor Winding Protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the field
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4-1/2˝ (115 mm)
Sanding Disc
4-1/2˝ (115 mm)
Diamond Wheel
4-1/2˝ (115 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
2,800 - 11,000 RPM
AMPS (120V)
12.0 A
GA4542C01:
Overall length 11-7/8˝ (303 mm)
Net Wieght
5.6 lbs. (2.5 kg)
GA4543C01:
Overall length 12-3/4˝ (325 mm)
Net Wieght
6.1 lbs. (2.8 kg)
STANDARD EQUIPMENT INCLUDES:
4-1/2˝ Depressed Centre Wheel (A-80640),
Vibration Proof Grip (162258-0), Lock Nut Wrench 28
(782412-6),Toolless Wheel CoverAssy (123144-0)
Inner Flange 45 (224399-1), Lock Nut 5/8-45(224568-4)
GA4542C01
GA4542C01, GA4543C01
4-1/2˝ Angle Grinders
"SJS" Technology,
Variable Speed
STANDARD EQUIPMENT INCLUDES:
4-1/2˝ Depressed Centre Wheel (A-80640),
Vibration Proof Grip (162258-0), Lock Nut Wrench 28
(782412-6),Toolless Wheel CoverAssy (123144-0),
Inner Flange 45B (224448-4), Lock Nut 5/8-45(224568-4)
GA4543C01
Mechanical
Brake
