109
STANDARD EQUIPMENT INCLUDES:
Socket Wrench (782210-8)
Used To Cut Steel, Concrete And Masonry Materials With
A Dry Cutting Diamond Blade
• Guide wheels on the tool guard ensure smooth tool travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• “SJS” technology prevents kickback if blade jams protecting both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
AC/DC, “SJS” Technology
14˝ Angle Cutter
SPECIFICATIONS
Blade Diameter
14˝ (355 mm)
Arbor
1˝ (25.4 mm)
Maximum Cutting Depth 5˝ (125 mm)
No Load Speed
3,500 RPM
AMPS (120V)
15.0 A
Overall Length
26-1/2˝ (673 mm)
Net Weight
22.7 lbs. (10.3 kg)
4114
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case (824697-4), Socket Wrench (782210-8)
Used To Cut Steel, Concrete And Masonry Materials With
A Dry Cutting Diamond Blade
• Guide wheels on the tool guard ensure smooth tool travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• “SJS” technology prevents kickback if blade jams protecting both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
AC/DC, “SJS” Technology
12˝ Angle Cutter
SPECIFICATIONS
Blade Diameter
12˝ (305 mm)
Arbor
1˝ (25.4 mm)
Maximum Cutting Depth 3-15/16˝ (100 mm)
No Load Speed
5,000 RPM
AMPS (120V)
15.0 A
Overall Length
25-1/2˝ (648 mm)
Net Weight
25.1 lbs. (11.4 kg)
4112H
Compact And Lightweight, Weighing In
At Just Over 36 Lbs
• Quick Release Vice
• Lock-Off button prevents accidental start up
• Spark Guard for operators safety
• Adjustable Depth Stop for precise, repeatable cutting depth
• Externally accessible carbon brushes
SPECIFICATIONS
Blade Diameter
14˝ (355 mm)
Arbor
1˝ (25.4 mm)
No Load Speed
3,800 RPM
Cutting Capacity:
45 Degrees
4-1/2˝ (114.3 mm)
90 Degrees
4-1/2˝ (114.3 mm)
AMPS (120V)
15.0 A
Overall Length
19-3/4˝ (500 mm)
Net Weight:
2414 NB
40.6 lbs. (18.4 kg)
2414 DB
37.3 lbs. (16.9 kg)
STANDARD EQUIPMENT INCLUDES:
1 Ea. 14"Abrasive Wheel (B-23204-5),
Socket Wrench (782210-8), Quick Vise (134548-1)
2414NB
Mitres 45° Left And Right
2414NB, 2414DB
14˝ Portable Cut-Off Saws
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
MAXIMUM CUT-OFF
SAW CUTTING CAPACITIES
METAL
Mitre
Model
Blade Diameter
Round Tubing
Square Tubing Rectangular Tubing
Angle
0° Mitre
2416S
16"
4-1/2"
4-1/2"
3-15/16" x 8-1/4"
4-1/2"
2414DB / 2414NB
14"
4-1/2"
4-11/16"
4-1/2" x 5-1/8"
5-3/8"
LC1230
12"
4-1/2"
-
3-5/16"
-
45° Mitre
Left or Right
2416S
16"
4-1/2"
4-5/16"
3-15/16" x 5-5/16"
4-5/16"
2414DB / 2414NB
14"
4-1/2"
4-3/16"
4-1/2" x 4-1/16"
3-15/16"
45° Mitre
Left
LC1230
12"
3-1/2"
3-1/2"
3-5/16" x 5-5/16"
3-1/2"
A
A
A
B
A
A
A
CUT OFF SAW BLADES (DRY CUTTING)
Blade Diameter
Arbor
Teeth
Recommended Use
Max RPM For Model
Part No.
12"
1"
60 CT
Mild Steel-Pipe (Black Iron, Cast Iron)
2,000
LC1230
A-90897
60 CT
Angle Iron, Tubing (Round, Square, Rectangular)
2,000
A-90722
76 CT
Stainless Steel (Pipe, Angle Iron, Tubing, Conduit, Threaded Rod)
1,500
A-91039
78 CT
Thin Mild Steel (Pipe, Angle Iron, Tubing)
2,000
A-90875
100 CT
14 ga - 16 ga Stainless Steel (Pipe, Angle Iron, Tubing, Conduit, Threaded Rod)
2,000
A-95803
AC / DC
STANDARD EQUIPMENT INCLUDES:
1 Ea. 14˝Abrasive Wheel (A-90168),
Socket Wrench (782210-8), Quick Vise (134548-1)
2414DB
14" DIAMOND CUT OFF SAW BLADE
D-42597
Description
For Models
• 14" Diameter / 1" Arbor
• 4,400 RPM No Load Speed
• Ideal for cutting ferrous
metals including steel pipe,
channel, angle iron, rebar,
strut, PVC pipe and more!
• Vacuum brazed diamond
segments for optimal
operational life and
performance
• Eliminates performance
issues of abrasive wheels,
including disc shrinkage,
glazing and shattering
• Offers up to 120x the life
of abrasive blades and
4x carbide blades
2414DB
2414NB
