Electric
Power Tools
makita.ca
113
STANDARD EQUIPMENT INCLUDES:
Grip (153504-2), Lock Nut Wrench (782424-9),Tool-less Wheel Cover (135110-5), 6˝ Depressed Centre Wheel (A-80846),
Inner Flange (224361-6), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Two Stage Safety Trigger Switch (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and
operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
“SJS” Technology, Electric Brake
6˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6˝ (150 mm)
Sanding Disc
6˝ (150 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14˝ (356 mm)
Net Weight
6.6 lbs. (3.0 kg)
GA6020Y
STANDARD EQUIPMENT INCLUDES:
Vibration Proof Grip (194514-0), Lock Nut Wrench 28 (782424-9), Inner Flange 82(224361-6), Lock Nut 5/8-45(224568-4),
Tool-less Wheel CoverAssy. (135110-5), 6" Depressed Centre Wheel (A-80846)
Trigger Switch with Lock-On Button (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Anti-Restart feature prevents accidental start up of tool if switch is locked in the on position
• LED Light indicates active power supply and activation of anti-restart feature
• Labyrinth construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the field
coils to act as an impenetrable barrier to dust and debris
“SJS” Technology, Electronic Current
Limiter, Constant Speed Control, Soft Start
6˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Wheel
6˝ (150 mm)
Sanding Disc
6˝ (150 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
9,000 RPM
AMPS (120V)
12.5 A
Overall Length
15-3/8˝ (390 mm)
Net Weight
6.6 lbs. (3.0 kg)
GA6020C
STANDARD EQUIPMENT INCLUDES:
Grip (153504-2), Lock Nut Wrench (782424-9),Tool-less Wheel Cover (135110-5), 6" Depressed Centre Wheel (A-80846), Inner Flange
(224361-6), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Trigger Switch with No Lock-On Button (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and
operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the field
coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
“SJS” Technology, Electric Brake
6˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6˝ (150 mm)
Sanding Disc
6˝ (150 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14˝ (356 mm)
Net Weight
6.6 lbs. (3.0 kg)
GA6020
STANDARD EQUIPMENT INCLUDES:
GA6010:
Grip (153504-2), Lock Nut Wrench (782424-9),Tool-less Wheel Cover (135110-5), 6˝ D.C.W. 36 Grit (A-80846),
Inner Flange (224361-6), Lock Nut (224568-4)
GA6010Z:
Grip (153504-2), Lock Nut Wrench (782424-9),Toolless Wheel Cover (135110-5), 6˝ D.C.W. 36 Grit (A-80846),
Inner Flange (224361-6), Lock Nut (224568-4)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left
or right side of tool
• Ergonomic soft rubber grip design for vibration
absorption and comfortable operation
6˝ Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6˝ (150 mm)
Sanding Disc
6˝ (150 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
10,000 RPM
AMPS (120V)
10.5 A
Overall Length
14˝ (356 mm)
Net Weight
6.0 lbs. (2.7 kg)
Trigger Switch with
Lock-On
Button (AC/DC)
GA6010
Trigger Switch with
No Lock-On
Button (AC/DC)
GA6010Z
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Thumb Switch with Lock-On (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electronic Current Limiter prevents motor burnout due to overloading
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Re-Designed Gear Housing for enhanced shaft lock durability
• Labyrinth Construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor Winding Protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the field
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6˝ (150 mm)
Sanding Disc
6˝ (150 mm)
Diamond Wheel
6˝ (150 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
4,000- 9,000 RPM
AMPS (120V)
12.0 A
GA6042C01:
Overall length 11-7/8˝ (303 mm)
Net Wieght
5.8 lbs. (2.6 kg)
GA6043C01:
Overall length 12-3/4˝ (325 mm)
Net Wieght
6.3 lbs. (2.9 kg)
STANDARD EQUIPMENT INCLUDES:
6˝ Depressed Centre Wheel (A-80846), Vibration Proof
Grip (162258-0), Lock Nut Wrench 28 (782412-6),
Toolless Wheel CoverAssy (123146-6),
Inner Flange 82 (224361-6), Lock Nut 5/8-45 (224568-4)
GA6042C01
GA6042C01, GA6043C01
6˝ Angle Grinders
"SJS" Technology,
Variable Speed,
Electronic Current
Limiter, Constant
Speed Control,
Soft Start
STANDARD EQUIPMENT INCLUDES:
6˝ Depressed Centre Wheel (A-80846), Vibration Proof
Grip (162258-0), Lock Nut Wrench 28 (782412-6),
Toolless Wheel CoverAssy (123146-6),
Inner Flange 82B (224454-9), Lock Nut 5/8-45 (224568-4)
GA6043C01
Mechanical
Brake
