METALWORKING
makita.ca
112
STANDARD EQUIPMENT INCLUDES:
Grip 36 Complete (152539-0), Lock Nut Wrench 28 (782412-6), Wheel Cover (122939-8), Inner Flange 89 (224317-9), Lock Nut (224568-4)
Paddle Switch with Lock-On Button (AC/DC)
• Compact gear housing increases maximum cutting depth by 1/4˝
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
7˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7˝ (180 mm)
Sanding Disc
7˝ (180 mm)
Wire Cup Brush
4-3/8˝ (110 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Overall Length
17˝ (432 mm)
Net Weight
9.9 lbs. (4.5 kg)
GA7050
STANDARD EQUIPMENT INCLUDES:
7˝ Depressed Centre Wheel (D-20806), Side Handle (152539-0), Inner Flange (224317-9), Lock Nut (224568-4),
Lock Nut Wrench (782412-6),Tool-less Wheel Cover ( 122772-8)
Paddle Switch with Lock-On Button (AC)
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Electronic Current Limiter, Soft Start
7˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7˝ (180 mm)
Sanding Disc
7˝ (180 mm)
Wire Cup Brush
4-3/8˝ (110 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
8,400 RPM
AMPS (120V)
15.0 A
Overall Length
17-7/8˝ (453 mm)
Net Weight
9.5 lbs (4.3 kg)
GA7010C
STANDARD EQUIPMENT INCLUDES:
7˝ Depressed Centre Wheel (D-20806),Tool-less Wheel CoverAssembly (122767-1), Side Handle (152539-0), Inner Flange (224317-9),
Lock Nut (224568-4), Lock Nut Wrench (782412-6)
Paddle Switch with Lock-On Button (AC/DC)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
7˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7˝ (180 mm)
Sanding Disc
7˝ (180 mm)
Wire Cup Brush
4-3/8˝ (110 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Overall Length
18-5/8˝ (473 mm)
Net Weight
12.1 lbs. (5.5 kg)
GA7020
STANDARD EQUIPMENT INCLUDES:
6˝ Depressed Centre Wheel (A-80846), Wheel Guard (134961-3),
Side Handle (152492-0), Inner Flange (224361-6), Lock Nut (224568-4), Lock Nut Wrench (782412-6)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at
every 90° for optimal positioning
• Removable side handle can be mounted on left
or right side of tool
6˝ Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
6˝ (150 mm)
Sanding Disc
6˝ (150 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
9,000 RPM
AMPS (120V)
12.5 A
Overall Length
15-3/8˝ (391 mm)
Net Weight
7.9 lbs. (3.6 kg)
9016DB
Has AC/DC Paddle Switch
9016DBZ
Has AC/DC Trigger Switch (Shown)
Paddle Switch
with Lock-On Button
(AC/DC)
9016DB
Trigger Switch
with Lock-On Button
(AC/DC)
9016DBZ
• Heavy duty torque limiter prevents damage to internal gearing and prevents operator from
experiencing a surge of torque during wheel lock up
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Includes rear vent ˝Dust Cover Assembly˝ for added protection against dust and debris (GA7031Y Only)
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rear handle swivels 180
°
to adjust to the most comfortable grinding position
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7˝ (180 mm)
Sanding Disc
7˝ (180 mm)
Wire Cup Brush
4-3/8˝ (110 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Overall Length
19-7/8˝ (504 mm)
Net Weight
13.9 lbs. (6.3 kg)
STANDARD EQUIPMENT INCLUDES:
Vibration Proof Grip (194543-3),
Lock Nut Wrench 28 (782412-6),
Tool-less Wheel CoverAssembly (122767-1)
Inner Flange 89 (224317-9), Lock Nut 5/8-45 (224568-4)
GA7031
Trigger Switch with
Lock-On Button
(AC/DC)
GA7031, GA7031Y
7˝ Angle Grinders
STANDARD EQUIPMENT INCLUDES:
Vibration Proof Grip (194543-3), Dust CoverAttachment Set (194289-1),
Lock Nut Wrench 28 (782412-6),Tool-less Wheel CoverAssembly (122767-1),
Inner Flange 89 (224317-9), Lock Nut 5/8-45 (224568-4)
GA7031Y
Two Stage Safety
Trigger Switch
(AC/DC)
