• Toolless chain tension adjustment for quick and easy adjustment on the jobsite
• Soft start feature gradually increases speed to eliminate start up shock
• Electronic current limiter prevents motor burnout due to overloading
• Electric brake for increased operator safety
• Automatic chain oiler maintains constant oil delivery regardless of temperature or oil viscosity
• Increased oil tank capacity enables longer operating time between refills
• Soft rubber grip design for comfortable operation
SPECIFICATIONS
Chain Pitch / Gauge
3/8˝ / .050˝
Chain Speed
2900 FPM
Oil Tank
200 ml
AMPS (120V)
14.5 A
Overall Length
19-7/8˝ (505 mm)
Net Weight:
UC3551A
12.1 lbs (5.5 kg)
UC4051A
12.3 lbs (5.6 kg)
STANDARD EQUIPMENT INCLUDES:
See makita.ca
UC4051A
16˝ Bar
(400 mm)
STANDARD EQUIPMENT INCLUDES:
See makita.ca
UC3551A
14˝ Bar
(350 mm)
Electric Brake
UC3551A, UC4051A
Electric Chainsaws
EA3501S40B
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (442 040 661), 16˝ Chain (528 092 656), Chain Cover 14˝-16˝ (952 010 640), Universal Wrench 13/16 (941 713 160)
16˝ Bar
• Touch & Stop Switch automatically returns switch
to start position, eliminating carburetor flooding
• Intelligent Ignition Coil controls stable idling,
increases output power, protects against engine
overrun and enables easier restarting
• Toolless Chain Tension Adjustment for quick and
easy adjustment on the jobsite
• Throttle-Lock Start Position
• External access holes allow easy
carburetor adjustment
• Primer pump for easy starting
• Automatic Chain Oiler
• Inertia Chain Brake
16˝ / 35 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement
35 cc. (2.1 cu.in)
Chain Pitch / Gauge
3/8˝ / .050˝
Maximum Engine Speed 13,100 RPM
Power Rating
1.7 kW / 2.3 H.P.
Fuel / Oil Mixture
50:1
Ignition System
Electronic
Fuel Tank Capacity
400 ml
Oil Tank Capacity
290 ml
Net Weight Dry w/o Bar/Chain
9.9 lbs (4.5 kg)
EA3201S40B
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (165202-6), 16˝ Chain (528 092 656), Chain Cover 16˝ (419560-5), Universal Wrench 13/16 (782026-1),
Screwdriver (783012-5), Spark Plug (650109950), Starter Rope (444038-9)
16˝ Bar
• Touch & Stop Switch automatically returns switch
to start position, eliminating carburetor flooding
• Intelligent Ignition Coil controls stable idling,
increases output power, protects against engine
overrun and enables easier restarting
• Toolless Chain Tension Adjustment for quick and
easy adjustment on the jobsite
• Throttle-Lock Start Position
• External access holes allow easy carburetor
adjustment
• Primer pump for easy starting
Rapid Start
16˝ / 32 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement
32 cc. (1.95 cu.in.)
Chain Pitch / Gauge
3/8˝ / .050˝
Maximum Engine Speed 12,800 RPM
Power Rating
1.35 kW / 1.8 H.P.
Fuel / Oil mixture
50:1
Ignition System
Electronic
Fuel Tank Capacity
400 ml
Oil Tank Capacity
280 ml
Net Weight Dry w/o Bar/Chain
9.4 lbs. (4.2 kg)
Rapid Start
DUC122Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
4-1/2" Chain, 4-1/2" Guide Bar (158476-6), Chain Cover (416311-7),
Chain File (744003-1), Oil Supply
Ideal For Cutting Small Diameter
Firewood Or Brush, Pruning
Applications And More
• Top handle design enables greater force to be
applied during cutting operations and creates
more compact design
• Hand guard protects operators hand
during operation
• Lock-off button prevents accidental startup
• Electric brake stops chain within
0.5 seconds for added safety
4-1/2˝ / 18 V Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Guide Bar Length
4-1/2˝ (115 mm)
Chain Pitch / Gauge
1/4˝ / .050”
Chain Speed
980 FPM (300 m/min)
Overall Length
16-5/8˝ (422 mm)
Net Weight
4.2 lbs (1.9 kg)
Electric Brake
DUC302Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
12" Chain (531 290 046), 12" Guide Bar (165245-8), Chain Cover (419288-5)
Makita's FIRST 36V (18VX2) Chainsaw!
Ideal For Cutting Firewood Or Brush, Pruning Applications And More!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, drbris and liquids for
optimal performance in extreme conditions
• Battery capacity warning light indicates ideal time to recharge battery
• Lock-off button prevents accidental startup
• Electric chain brake provides maximum operator safety if kickback occurs
• Tool-less chain tension adjustment for quick and easy adjustment on the jobsite
• Automatic chain oiler
• Metal lanyard hook enables quick attachment to lanyard during climbing or bucket operations
12˝
/ 36V Cordless Chainsaw
SPECIFICATIONS
Battery
Two 18V Li-Ion
Guide Bar Length
12˝ (300 mm)
Chain Pitch / Gauge
3/8˝ / 0.043˝
Chain Speed
1,650 FPM (500 m/min)
Overall Length
22-3/4˝ (577 mm)
Net Weight
7.7 lbs (3.5 kg)
Electric Chain Brake
Batteries Shown
Not Included
