DUR181Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Nylon Cord (196148-5), Bump & Feed Spool Set (196146-9), BandAssembly
(125516-5), Safety Cover (453353-0), Front Grip (453340-9), Safety Goggles (195246-2)
Well Balanced Design With Fully Adjustable Features To Suit Any Operator
• Adjustable Trimmer Head features 5 angled cutting positions for maximum versatility and ease
of operation when trimming around obstacles
• Trimmer Head Rotates 180° to enable easy edge trimming
• Telescopic Shaft adjusts quickly and easily to suit any operator
• Lock-Off Safety Lever prevents accidental start up
• Battery Capacity Warning Light indicates low battery capacity
10-1/4˝ / 18V Cordless Line Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
7,800 RPM
Cutting Width
10-1/4˝ (260 mm)
Overall Length
56-1/2˝ (1,433 mm)
Net Weight
4.4 lbs (2.0 kg)
Replacement Nylon Cutting Line
196148-5 (49') or 195861-2 (98')
HKU01ZX2
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
Direct Connect Battery Converter BCV02 (195850-7)
Lightweight Design with High Efficiency, Zero Emissions
and Low Noise Level
• Zero Emissions and Low Noise Level ideal for use in sensitive work environments,
including residential areas and more
• Adjustable 3-Stage Handle enables positioning at optimal angle of operation or for more compact
storage when not in use
• Battery Capacity Warning Light indicates approximate remaining battery power for each battery
• Transport Wheels enable easy movement around the work site and can be folded upright when not in use
• Carrying Handles enable easier loading or unloading from vehicle or trailer
• 2-Step Switch / Handle Lever Starting System and
Child Lock Key prevents accidental start up for
maximum safety
13-3/4˝ / 36V Cordless Cultivator
SPECIFICATIONS
Battery Capacities:
36V (2.6 Ah) Li-Ion
Two 18V (3.0 Ah) Li-Ion
No Load Speed:
Tine Axle Speed
85 RPM
Motor Speed
4,100 RPM
Cultivating Width
13-3/4˝ / 8-7/8˝ (350 / 225 mm)
Tine Diameter
9-5/8˝ (245 mm)
Transmission Speeds
1-Forward
Dimensions (L x W x H)
47˝x 19-1/4˝x 39-1/4˝
(1,193 mm x 488 mm x 998 mm)
Net Weight
48.5 lbs (22.2 kg)
BCV02
Makita's FIRST 18VX2 Line Trimmer!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, drbris and liquids for optimal performance in extreme conditions
• Battery fuel gauge indicates approximate remaining battery power
• Brushless DC motor with high power to weight and size ratio
• Zero emissions and low noise level ideal for use in sensitive work environments, including residential areas and more
• Current limiter prevents motor burnout due to high temperatures caused by overloading
• Two stage safety trigger with auto shut-off feature for increased operator safety
• Reversing function allows operator to quickly clear trimmer head of entangled grass and weeds
• Electric brake for increased operator safety
• Variable speed settings alow operator to adjust cutting speed based on materials or application
• 12˝ cutting path (using standard equipment string trimmer head)
SPECIFICATIONS
Battery
Two 18V Li-Ion
Cutting Width
12" (300 mm)
No Load Speed
3,500 - 6,600 RPM
Dimensions (L x W x H)
73" x 11-1/4" x 9-11/16"
(1854 mm x 286 mm x 246 mm)
Net Weight
9.7 lbs (4.4 kg)
DUR362LZ
36 V 12
˝
Cordless Line Trimmer
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
BandAssembly (125516-5),
Bump and FeedTrimmer HeadAssy (196871-2), Safety Goggles (195246-2), Loop Handle (195626-2),
Hex Wrench 5 (783217-7), Hex Wrench 4 (783202-0),Accessory Bag (831304-7), Protector (454640-0)
Batteries Shown
Not Included
DUB361Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shoulder Belt (166095-4), Long Nozzle (452123-4)
Makita's FIRST 36V (18VX2) Blower!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
• optimal performance in extreme conditions
• Battery capacity warning light indicates ideal time to recharge battery
• Low noise level suitable for use in residential areas and public spaces
• Push button air volume selection (low / high settings)
• Long blowing nozzle with curved tip for optimal blowing performance
• Shoulder belt for operator convenience
36V Cordless Blower
SPECIFICATIONS
Battery
Two 18V Li-Ion
Continuous Run Time (Approx.)
30 min. (Low) / 14 min. (High)
Maximum Air Volume
92 ft
3
/min (Low) / 155 ft
3
/min (High)
Maximum Air Speed
187 ft/sec (Low) / 305 ft/sec (High)
No Load Speed (RPM)
10,000 RPM (Low) / 17,000 RPM (High)
Overall Length
35-5/8˝ (905 mm)
Net Weight
4.2 (1.9 kg)
Electric Brake, Variable Speed,
Reversible
DLM380Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade Set (196863-1), Grass Catcher (DA00000357), Offset Wrench 13 (782016-4)
Compact and Lightweight Design with Zero Emissions and Low Noise Level
• Zero emissions and low noise level ideal for use in sensitive work environments, including
residential areas and more
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Adjustable handle enables positioning at optimal angle of operation or for more compact storage
when not in use
• 6-step single-lever cutting height adjustment for easy adjustment
• Grass level indicator allows
operators to quickly check
approximate remaining capacity
of grass clipping bag
36V Cordless Lawn Mower
SPECIFICATIONS
Battery
Two 18V Li-Ion
Cutting Width
15˝ (380 mm)
Cutting Height Adjustment
6 Heights
Grass Box Capacity
40 L
No Load Speed
3,700 RPM
Dimensions (L x W x H)
45˝ x 18-1/4˝x 40-1/4˝
(1,145 mm x 465 mm x 1,023 mm)
Net Weight
31.7 lbs. (14.4 kg)
