LITHIUM-ION
makita.ca
20
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DJV180RFE
STANDARD EQUIPMENT INCLUDES:
DJV180RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Jig Saw Blade Set (2 Ea. B-10, BR-13, B-22)
(792724-9), Hex Wrench 4 (783202-0),Anti-Splintering Device (415524-7), Cover Plate (417852-6), Plastic Carrying Case (824775-5)
DJV180F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Jig Saw Blade Set (2 Ea.: B-10, BR-13, B-22) (792724-9),
Hex Wrench 4 (783202-0),Anti-Splintering Device (415524-7), Cover Plate (417852-6)
DJV180Z:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blade Set (2 Ea.: B-10, BR-13, B-22) (792724-9),
Hex Wrench 4 (783202-0),Anti-Splintering Device (415524-7), Cover Plate (417852-6)
Tool-Less Blade Change For Fast Blade Installation And Removal
• Large Variable Speed 2 finger trigger switch
• 3 Orbital settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• LED Job Light illuminates work area
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Tool-Less Blade Change, Variable Speed
Cordless Jig Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Depth:
Steel
3/8˝ (10 mm)
Wood
5-5/16˝ (135 mm)
Aluminum
25/32˝ (20 mm)
Stroke Per Minute
0-2,600 SPM
Length of Stroke
1˝ (26 mm)
Overall Length
10-1/8˝ (257 mm)
Net Weight
6.2 lbs. (2.8 kg)
DJV180F
DJV180Z
STANDARD EQUIPMENT INCLUDES:
1 Ea. Blade (B-20432, 723063-A-5), Hex Wrench 3 (783201-2)
Ultra-Compact And Lightweight Design For Maximum Versatility
and Maneuverability
• Multi-position switch (tool handle & tool body) with lock-off levers for easier operation, maximum
versatility and operator safety
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• One-handed, fast tool-less blade changes
• LED joblight with afterglow feature
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Cordless Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
2˝ (50 mm)
Wood (w/12" blade)
2˝ (50 mm)
Strokes Per Minute
0 - 3,000 SPM
Length of Stroke
1/2˝ (13 mm)
Overall Length
15-5/8˝ (398 mm)
Net Weight
2.7 lbs (1.2 kg)
DJR183Z
DJR181RFE
STANDARD EQUIPMENT INCLUDES:
DJR181RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),Charger(DC18RC),BladeSet(194068-7),
PlasticCarryingCase(824760-8)
DJR181F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Blade Set (194068-7)
DJR181Z:
Tool Only. Batteries and Charger Sold Separately.
Blade Set (194068-7)
• One-Handed, Fast Tool-Less Blade Changes
• Tool-Less shoe adjustment
• Dual LED Lights illuminate cutting area
• Retractable Sky Hook for hanging on rafters, pipes or scaffolding
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Tool-Less Blade Change, Variable Speed
Cordless Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
5-1/8˝ (130 mm)
Wood (w / 12˝ blade)
10˝ (255 mm)
Strokes Per Minute
0 - 2,900 SPM
Length of Stroke
1-1/8˝ (28mm)
Overall Length
19-5/8˝ (499 mm)
Net Weight
8.2 lbs. (3.7 kg)
DJR181F
DJR181Z
DJR182RFE
STANDARD EQUIPMENT INCLUDES:
DJR182RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),Charger(DC18RC),BladeSet(194068-7),
PlasticCarryingCase(824818-3)
DJR182F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Blade Set (194068-7)
DJR182Z:
Tool Only. Batteries and Charger sold separately.
Blade Set (194068-7)
• One-Handed, Fast Tool-Less Blade Changes
• Tool-Less shoe adjustment
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Tool-less Blade Change, Variable Speed
Cordless Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
5-1/8˝ (130 mm)
Wood (w/12˝ blade)
10˝ (255 mm)
Strokes Per Minute
0 - 2,900 SPM
Length of Stroke
1-1/8˝ (28 mm)
Overall Length
17-3/4˝ (449 mm)
Net Weight
7.9 lbs (3.6 kg)
DJR182F
DJR182Z
STANDARD EQUIPMENT INCLUDES:
DKP180RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), 3-1/4˝ C.T. Mini Planer Blade (A-82921),
BladeGuideAssembly(123010-1),SocketWrench9(782209-3),GuideRule(165581-2),BatteryCover(450128-8),PlasticCarryingCase(824982-0)
DKP180F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), 3-1/4˝ C.T. Mini Planer Blade (A-82921), Blade GuideAssembly (123010-1),
Socket Wrench 9 (782209-3), Guide Rule (165581-2)
DKP180Z:
Tool Only. Batteries and Charger Sold Separately.
3-1/4˝ C.T. Mini Planer Blade (A-82921), Blade GuideAssembly (123010-1),
Socket Wrench 9 (782209-3), Guide Rule (165581-2)
Incorporates Makita's Battery Protection System
• Battery Protection System provides Over-Discharge, Temperature and Current Protection for
enhanced performance, battery cycle life and overall battery life
• Base Plate Foot protects materials and blade from damage
• Single Chamfering Groove enables quick and easy chamfering of corners
• Depth Adjustment Knob with Click Stops for precision planing applications
• Large Lock-Off Safety Lever prevents accidental start up
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3-1/4˝ Cordless Planer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
14,000 RPM
Maximum Capacities:
Planing Width
3-1/4˝ (82 mm)
Planing Depth
5/64˝ (2 mm)
Shiplapping
11/32˝ (9 mm)
Overall Length
13-1/8˝ (333 mm)
Net Weight
7.5 lbs. (3.4 kg)
Electric Brake
DKP180RFE
DKP180Z
DKP180F
DGA452RFE
STANDARD EQUIPMENT INCLUDES:
DGA452RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), 4-1/2” Depressed Center Wheel (D-20781),
DCW Wheel Cover (125267-0), 1 Ea. 4-1/2"Thin Kerf Cut Off Wheel (724115A25)TKCOW Wheel Cover (135103-2), Lock Nut Wrench
(782424-9), Side Handle (158237-4), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4), Plastic Carrying Case (824767-4)
DGA452F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), 4-1/2˝ Depressed Center Wheel (D.C.W) (D-20781),
DCW Wheel Cover (125267-0), 1 Ea. 4-1/2˝Thin Kerf Cut Off Wheel (724115A25),TKCOW Wheel Cover (135103-2), Side Handle (158237-4),
Lock Nut Wrench (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8˝-45 (224568-4)
DGA452Z:
Tool Only. Batteries and Charger Sold Separately.
4-1/2” Depressed Center Wheel (D.C.W) (D-20781), DCW Wheel Cover
(125267-0), 1 Ea. 4-1/2"Thin Kerf Cut Off Wheel (724115A25),TKCOW Wheel Cover (135103-2), Side Handle (158237-4), Lock Nut Wrench
(782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4)
High Power, Lightweight Angle Grinder
• Electronic Current Limiter with Warning Light prevents motor burnout caused by overloading
• Low Battery Capacity Light indicates ideal time to recharge battery
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch
is locked in the on position
• Conveniently located thumb switch for operator comfort
• Removable side handle can be mounted on either side of grinder body
Toggle Switch
4-1/2˝ Cordless Angle Grinder
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
4-1/2˝ (115 mm)
No Load Speed
10,000 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
12-1/2˝ (317 mm)
Net Weight
5.1 lbs. (2.3 kg)
DGA452F
DGA452Z
