214 / 220
MANUFACTURING&ASSEMBLY
makita.ca
212
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
BFT123FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
Reversible
1/4" Precise Torque Screwdrivers
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4"
No Load Speed
390 RPM
Fastening Torque
5-12 Nm. (44.3 - 106 in./lbs)
Width
2-13/16" (71 mm)
Height (With Battery)
11-1/8" (283 mm)
Length
7-7/8" (200 mm)
Net Weight
2.2 lbs (1.0 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
USB Cable (661432-2),TorqueAdjustmentTool (765027-4), Lock Nut (457530-6)
Programmable Speed Control For Maximum Fastening Precision And Accuracy
• Precise torque control consistently delivers repeatability of +/- 10%
• Programmable speed control enables user to control speed of hard or soft joints or production
time using USB / PC connection
• Brushless DC motor with high power to weight and size ratio
• On board LED and audible signal informs user of successful run down
• Battery capacity warning light indicates ideal time
to recharge battery
Programmable
Speed Control,
Reversible
1/4" Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4"
Width
2-13/16" (72 mm)
Height (With Battery)
9-3/4" (249 mm)
Length (With Battery)
6-1/4" (159 mm)
Net Weight
1.8 lbs (0.8 kg)
No Load Speed:
DFT023FMZ
400 - 1,300 RPM
DFT045FMZ
150 - 900 RPM
Fastening Torque:
DFT023FMZ
0.5 - 2 Nm. (4 - 18 in./lbs)
DFT045FMZ
1 - 4 Nm. (9 - 35 in./lbs)
DFT045FMZ
DFT023FMZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
USB Cable (661432-2),TorqueAdjustmentTool (765027-4), Ring 25 (424977-9)
Programmable Speed Control For Maximum Fastening Precision And Accuracy
• Precise torque control consistently delivers repeatability of +/- 10%
• Programmable speed control enables user to control speed of hard or soft joints or production
time using USB / PC connection
• Brushless DC motor with high power to weight and size ratio
• On board LED and audible signal informs user of successful run down
• Battery capacity warning light indicates ideal time
to recharge battery
Programmable
Speed Control,
Reversible
1/4" Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4"
Width
2-13/16" (72 mm)
Height (With Battery)
10" (254 mm)
Length (With Battery)
7-1/2" (190 mm)
Net Weight
2.3 lbs (1.0 kg)
No Load Speed:
DFT085FMZ
150 - 900 RPM
DFT127FMZ
100 - 600 RPM
Fastening Torque:
DFT085FMZ
3 - 8 Nm. (27 - 71 in./lbs)
DFT127FMZ
5 - 12 Nm. (44 - 106 in./lbs)
DFT127FMZ
DFT085FMZ
For Battery and Charger Compatibility
please refer to pages 59–61
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Bluetooth
®
Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to withstand high volume assembly processes
Reversible
1/4" Precise Torque Screwdriver
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4"
No Load Speed
860 RPM
Fastening Torque
4 - 8 Nm. (35 - 71 in./lbs)
Width
2-13/16" (72 mm)
Height (With Battery)
10-1/2" (266 mm)
Length (With Battery)
7-1/2" (191 mm)
Net Weight
2.2 lbs (1.0 kg)
DFT082RZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Bluetooth
®
Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to withstand high volume assembly processes
Reversible
1/4" Precise Torque Screwdriver
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4"
No Load Speed
600 RPM
Fastening Torque
6 - 12 Nm. (53 - 106 in./lbs)
Width
2-13/16" (72 mm)
Height (With Battery)
10-1/2" (266 mm)
Length (With Battery)
7-1/2" (191 mm)
Net Weight
2.2 lbs (1.0 kg)
DFT124RZ
BFL201RZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Bluetooth
®
Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers
repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque
and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to
withstand high
volume assembly
processes
3/8" Torque Tracer Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8"
Width
2-13/16" (72 mm)
Height (With Battery)
3-7/8" (98 mm)
Length (With Battery)
16-7/8" (429 mm)
Net Weight
2.6 lbs (1.2 kg)
No Load Speed:
BFL201RZ
360 RPM
BFL301RZ
260 RPM
Fastening Torque:
BFL201RZ
10 - 20 Nm. (88.5 – 177 in./lbs)
BFL301RZ
16 - 30 Nm. (142 – 266 in./lbs)
BFL301RZ
Reversible
