215 / 220
Cordless
Power Tools
makita.ca
213
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DFL400FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately.
TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8" Precise Torque Angle Wrench
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8"
No Load Speed
260 RPM
Fastening Torque
25 - 40 Nm.
(221 – 354 in./lbs)
Width
2-7/8" (73 mm)
Height (With Battery)
4-1/8" (104 mm)
Length (With Battery) 20-1/16" (510 mm)
Net Weight
3.3 lbs (1.5 kg)
DFL082FZ DFL122FZ DFL202FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Designed and manufactured to withstand
high volume assembly processes
3/8" Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8"
Width
2-15/16" (74 mm)
Height (With Battery)
3-7/8" (98 mm)
Length (With Battery)
16-5/8" (422 mm)
Net Weight
2.6 lbs (1.2 kg)
No Load Speed:
DFL082FZ
700 RPM
DFL122FZ
410 RPM
DFL202FZ
220 RPM
Fastening Torque:
DFL082FZ
2 - 8 Nm. (18 – 71 in./lbs)
DFL122FZ
5 - 12 Nm. (44 – 106 in./lbs)
DFL202FZ
8 - 20 Nm. (71 – 177 in./lbs)
Reversible
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for
outstanding ergonomics
• On board LED and audible signal informs user of
successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand
high volume assembly processes
1/4" Precise Torque Screwdrivers
SPECIFICATIONS
Battery
9.6V Ni-MH
Capacity (Driving Shank)
Hex
1/4"
Width
2-9/16" (65 mm)
Height (With Battery)
10-3/4" (274 mm)
Length (With Battery)
7-7/8" (200 mm)
Net Weight
2.2 lbs (1.0 kg)
No Load Speed:
BFT080FZ
540 RPM
BFT122FZ
320 RPM
Fastening Torque:
BFT080FZ
3 - 8 Nm. (26.6 – 70.8 in./lbs)
BFT122FZ
5 - 12 Nm. (44.3 – 106 in./lbs)
Reversible
Reversible
Anti-Kick Back Attachment
195620-4
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications
(Sold Separately)
BFT080FZ BFT122FZ
For Battery and Charger Compatibility
please refer to pages 59–61
DFL300FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately.
TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8" Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8"
Width
2-7/8" (73 mm)
Height (With Battery)
4-1/8" (104 mm)
No Load Speed
400 RPM
Fastening Torque
16 - 30 Nm. (142 – 266 in./lbs)
Length (With Battery) 19-15/16" (506 mm)
Net Weight
3.1 lbs (1.4 kg)
Anti-Kick Back Attachment
195620-4
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications
(Sold Separately)
Reversible
DFL083FZ DFL125FZ DFL204FZ DFL302FZ DFL403FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
USB Cable (661432-2)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Programmable speed control enables user to control speed of hard or soft joints or production
time using USB connection
• Brushless DC motor with high power to weight and size ratio
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• Battery capacity warning light indicates ideal time to recharge battery
• Auto battery shut off system warns of low battery capacity and shuts tool off when it can no longer
maintain accurate torque
• Soft start feature gradually increases rotational speed to eliminate start up shock
• On board LED and audible signal informs user of successful rundown
• LED job light with afterglow function illuminates fastening position
• Conveniently located forward / reverse push button switch for easy operator access
• Designed and manufactured to withstand high
volume assembly processes
3/8" Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8"
Width
2-15/16" (74 mm)
Height (With Battery)
3-7/8" (98 mm)
No Load Speed:
DFL083FZ
150 - 700 RPM
DFL125FZ
100 - 700 RPM
DFL204FZ
100 - 440 RPM
DFL302FZ
70 - 230 RPM
DFL403FZ
50 - 220 RPM
Fastening Torque:
DFL083FZ
2 - 8 Nm. (18 – 71 in./lbs)
DFL125FZ
5 - 12 Nm. (44 – 106 in./lbs)
DFL204FZ
8 - 20 Nm. (71 – 177 in./lbs)
DFL302FZ
16 - 30 Nm. (142 – 266 in./lbs)
DFL403FZ
25 - 40 Nm. (221 – 354 in./lbs)
Length (With Battery):
DFL083FZ
19" (481 mm)
DFL125FZ
19" (481 mm)
DFL204FZ
19" (481 mm)
DFL302FZ
20-1/2" (520 mm)
DFL403FZ
20-1/2" (520 mm)
Net Weight:
DFL083FZ
3.1 lbs (1.4 kg)
DFL125FZ
3.1 lbs (1.4 kg)
DFL204FZ
3.1 lbs (1.4 kg)
DFL302FZ
3.7 lbs (1.7 kg)
DFL403FZ
3.7 lbs (1.7 kg)
Anti-Kick Back Attachments
199065-8 / 199066-6
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications
(Sold Separately)
• 199065-8 (For DFL083FZ, DFL125FZ & DFL204FZ)
• 199066-6 (For DFL302FZ & DFL403FZ)
Programmable
Speed Control,
Reversible
