TD091DZ
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
High Operational Efficiency With Ultra-Compact Design
• Heavy-duty design with 4-pole motor for maximum operational efficiency and reliability
• Electric brake stops driver bit immediately after trigger is released to prevent over-tightening of fasteners
• Short trigger stroke (just 1/4"!) minimizes operator fatigue during periods of prolonged use in
manufacturing / production applications
• Battery capacity warning light indicates ideal time to recharge battery
• Automatic battery shut-off system protects against over-discharge of cells and incomplete fastening
due to low battery power
• LED job light with pre-glow feature
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed,
Reversible,
Electric Brake
1/4" Impact Driver
SPECIFICATIONS
Battery
12V MAX Li-Ion
Capacity (Driving Shank)
Hex
1/4"
No Load Speed
0 - 2,400 RPM
Impacts Per Minute
0 - 3,000 IPM
Fastening Torque 90 Nm. (800 in./lbs)
Width
2-1/8" (54 mm)
Height
7-7/8" (200 mm)
Length
5-1/4" (134 mm)
Net Weight
1.6 lbs (0.7 kg)
STANDARD EQUIPMENT INCLUDES:
DTD134RFE:
Two 14.4V (3.0Ah) Li-Ion Batteries
BL1430B (194066-1), Rapid Charger (DC18RC),
Battery Cover (450128-8), Hook (346449-3), Plastic Carrying Case (141856-3)
DTD134Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Compact and Lightweight Design with Overall Length of 5-7/16"
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Battery Protection System provides Over-Discharge, Temperature and Circuit Protection for
enhanced performance, battery cycle life and overall battery life
•
Increased Max. Torque of 1,370 in. lbs
• One-Touch Bit Holder enables quick and easy bit installation
• Battery Power Warning
light indicates
approximate remaining
battery power
• LED Light with Pre-Glow
and Afterglow feature
• Glow in the Dark Bumper
1/4" Impact Driver
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Hex Shank
1/4"
No Load Speed
0 - 2,400 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque
1,370 in. lbs (155 Nm)
Overall Length
5-7/16" (138 mm)
Net Weight
3.1 lbs (1.4 kg)
Variable Speed,
Reversible
DTD134Z
DTD134RFE
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
1/4" Impact Drivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (driving shank)
Hex
1/4"
Impacts Per Minute
0 - 3500 IPM
Width
2-15/16" (74 mm)
Height (with battery)
8-1/2" (216 mm)
Length
5-5/8" (144 mm)
No Load Speed:
DTD044Z
0 - 2300 RPM
DTD064Z
0 - 2500 RPM
BTD104Z
0 - 2700 RPM
Fastening Torque Up To:
DTD044Z
35 Nm. (310 in./lbs)
DTD064Z
65 Nm. (575 in./lbs)
BTD104Z
95 Nm. (841 in./lbs)
Net Weight:
DTD044Z
1.8 lbs (0.8 kg)
DTD064Z
1.6 lbs (0.7 kg)
BTD104Z
1.8 lbs (0.8 kg)
High Fastening Precision With
Compact And Lightweight Design
• Automatic battery shut-off system warns operator
visually and audibly to prevent incomplete fastening
due to low remaining battery power
• Automatic impact stop system prevents over or
under-tightening by stopping the motor after
completing a pre-set number of impacts
Use only with 14.4V Compact
Li-Ion Battery BL1415NA
(Part No. 196987-3)
Variable / Reversible
LED Display
Panel
DTD044Z DTD064Z BTD104Z
For Battery and Charger Compatibility
please refer to pages 59–61
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
3/8"
Impact Wrench
SPECIFICATIONS
Battery Capacities
14.4V Li-Ion
Capacity (Driving Shank)
Square
3/8"
Impacts Per Minute
0 – 3500 IPM
Width
2-15/16" (74 mm)
Height (With Battery)
8-1/2" (216 mm)
Length
5-5/8" (144 mm)
Net Weight
1.8 lbs (0.8 kg)
No Load Speed:
BTW104Z
0 – 2700 RPM
BTW074Z
0 – 2500 RPM
Fastening Torque Up To:
BTW104Z
95 Nm. (841 in./lbs)
BTW074Z
65 Nm. (575 in./lbs)
BTW074Z
BTW104Z
High Fastening Precision With Compact And Lightweight Design
• Automatic battery shut-off system warns operator visually and audibly to prevent incomplete fastening
due to low remaining battery power
• Automatic impact stop system prevents over or under-tightening by stopping the motor after
completing a pre-set number of impacts
• LED display panel enables number of impacts to be easily set and quickly referenced during operation
• Torque stabilization system detects remaining battery capacity to ensure consistent delivery of
torque versus impact time
Use only with 14.4V Compact
Li-Ion Battery BL1415NA
(Part No. 196987-3)
Variable / Reversible
LED Display
Panel
BFL120FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8" Precise Torque Angle Wrenches
SPECIFICATIONS
Battery
9.6V Ni-MH
Capacity (Driving Shank)
Square
3/8" (9.5 mm)
No Load Speed
250 RPM
Fastening Torque
5 - 12 Nm. (44.3 - 106 in./lbs)
Width
2-9/16" (65 mm)
Height (With Battery) 2-15/16" (74.0 mm)
Length (With Battery)
17.0" (430 mm)
Net Weight
2.4 lbs (1.1 kg)
Reversible
BFL081FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high
volume assembly processes
Reversible
3/8" Precise Torque Angle Wrenches
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Square
3/8"
Width
2-13/16" (71 mm)
Height (With Battery)
3-5/8" (92 mm)
Length (With Battery)
17.0" (430 mm)
Net Weight
2.4 lbs (1.1 kg)
No Load Speed:
BFL081FZ
700 RPM
BFL121FZ
410 RPM
Fastening Torque:
BFL081FZ
2 - 8 Nm. (17.7 – 70.8 in./lbs)
BFL121FZ
5 - 12 Nm. (44.3 – 106 in./lbs)
BFL121FZ
