STANDARD EQUIPMENT INCLUDES:
Tool-Kit (282-290301-H0),Two Spark Plugs (065-01402-80), (Battery Not Included)
Electric Start
• RECEPTACLES: Duplex 120V (20 AMP), Locking 120V (20 AMP), Locking 120V (30 AMP),
Locking 120V / 240V (30 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, Idle switch features full
power mode, Low oil automatic shut-off, Auto
decompression / Electronic ignition, Overhead
valve for more fuel efficiency
8.2 Hours Of Continuous Operation
12,000W / 653cc 4-Stroke Generator
SPECIFICATIONS
Maximum Output Current
12,000W
(100 / 50 AMP)
Rated Output Current 9,500W / 79.2 / 39.6 A
AC Voltage
60 Hz (120V / 240V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
653cc
Maximum Power
22 HP @ 3,600 RPM
Fuel Tank Capacity
44 L
Continuous Operation
8.2 Hrs (at high RPM)
Noise Level
77 dB
Dimensions (L x W x H)
32.5" x 24.1" x 30.4"
(826 mm x 611 mm x 771 mm)
Dry Weight
310.0 lbs (141 kg)
G12000R
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Socket Wrench 17 (782210-8), Elbow Joint (P-80008)
Used To Cut Steel, Concrete And Masonry Materials
• Guide wheels on the tool guard ensure smooth tool travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• “SJS” technology prevents kickback if blade jams protecting both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
AC/DC, SJS Technology
14" Angle Cutter
SPECIFICATIONS
Blade Diameter
14" (355 mm)
Arbor
1" (25.4 mm)
Maximum Cutting Depth
5" (125 mm)
No Load Speed
3,800 RPM
AMPS (120V)
15.0 A
Overall Length
26-1/2" (673 mm)
Net Weight
22.7 lbs (10.3 kg)
4114
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case (824697-9), Socket Wrench 17 (782210-8)
Used To Cut Steel, Concrete And Masonry Materials
• Guide wheels on the tool guard ensure smooth tool travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• “SJS” technology prevents kickback if blade jams protecting both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
AC/DC, SJS Technology
12" Angle Cutter
SPECIFICATIONS
Blade Diameter
12" (305 mm)
Arbor
1" (25.4 mm)
Maximum Cutting Depth 3-15/16" (100 mm)
No Load Speed
5,000 RPM
AMPS (120V)
15.0 A
Overall Length
25-1/2" (648 mm)
Net Weight
25.1 lbs (11.4 kg)
4112H
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-2)
Ultra-Compact And Lightweight Design For Maximum Versatility
and Maneuverability
• Multi-position switch (tool handle & tool body) with lock-off levers for easier operation, maximum
versatility and operator safety
• Battery protection system provides over-discharge,
temperature and circuit protection for
enhanced performance, battery cycle life
and overall battery life
• One-handed, fast tool-less blade changes
• LED joblight with afterglow feature
18V LXT Cordless Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
2" (50 mm)
Wood (12" Blade)
2" (50 mm)
Strokes Per Minute
0 - 3,000 SPM
Length of Stroke
1/2" (13 mm)
Overall Length
15-5/8" (398 mm)
Net Weight
2.7 lbs (1.2 kg)
DJR183Z
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-J0), Strainer (480-08310-33), Starter Rope (279-50110-08), Spark Plug (065-01402-10)
• 92' Total Head (Total height at sea level, to which water can be raised above original water level)
• Electronic sensor shuts off engine if oil is low
• Self priming pump for easy operation
• Mechanical seal made of Silicone-Carbide
• Powered by Robin Engines, Engine model # EX27
3" / 9.0 HP 4-Stroke Trash Pump
SPECIFICATIONS
Suction / Discharge Diameter 3" (76.2 mm)
Total Head
92' (28 m)
Suction Head
26' (8.0 m)
Maximum Pumping Capacity:
Litres Per Minute
1,300 LPM
Run Time (Per Tank, Full Load)
2.3 Hrs
Maximum Power
9.0 HP
Fuel Tank Capacity
6.1 L
Dimensions (L x W x H)
26.5" x 19.1" x 24"
(672 mm x 484 mm x 610 mm)
Dry Weight
106.9 lbs (48.5 kg)
EW320TR
HKU01ZX2
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Direct Connect Battery Converter
Lightweight Design with High Efficiency, Zero Emissions
and Low Noise Level
• Zero Emissions and Low Noise Level ideal for use in sensitive work environments,
including residential areas and more
• Adjustable 3-Stage Handle enables positioning at optimal angle of operation or for more compact
storage when not in use
• Battery Capacity Warning Light
indicates approximate remaining
battery power for each battery
• Transport Wheels enable easy
movement around the work site
and can be folded upright
when not in use
13-3/4" / 18Vx2 LXT Cordless Cultivator
SPECIFICATIONS
Battery Capacities:
36V Li-Ion
Two 18V Li-Ion
No Load Speed:
Tine Axle Speed
85 RPM
Motor Speed
4,100 RPM
Cultivating Width
13-3/4" / 8-7/8" (350 / 225 mm)
Tine Diameter
9-5/8" (245 mm)
Transmission Speeds
1-Forward
Dimensions (L x W x H)
47" x 19-1/4" x 39-1/4"
(119 cm x 49 cm x 100 cm)
Net Weight
48.5 lbs (22.2 kg)
