213 / 220
EW1050H
makita.ca
211
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
OUTDOOR
Power Equipment /
MANUFACTURING&ASSEMBLY
STANDARD EQUIPMENT INCLUDES:
Three Hose Clamp (ME01676330), Suction Hose (ME01676336),Two Hose Coupling (ME08121009), Socket Wrench (ME08121017),
Starter Rope (444019-3), Spark Plug (0650109950), Strainer (ME01689268),Adapter (ME08121060)
Increased Pumping Capacity, Suction Head and Total Head For
Maximum Operational Efficiency
• 135' Total Head (Total height at sea level, to which water can be raised above original water level)
• Super low noise muffler
• Three-Vane impeller with semi-open design for efficient water flow
• Self priming pump for easy operation
1" / 1.0 HP 4-Stroke Centrifugal Water Pump
SPECIFICATIONS
Suction / Discharge Diameter 1" (25.4 mm)
Total Head
135' (41 m)
Suction Head
29' (8.7 m)
Maximum Pumping Capacity:
Litres Per Minute
110 LPM
Maximum Power
1.0 HP
Fuel Tank Capacity
500 ml
Run Time (Per Tank, Full Load)
0.9 hrs
Dimensions (L x W x H)
12-1/2" x 9-1/8" x 12-7/8"
(319 mm x 231 mm x 327 mm)
Dry Weight
12.8 lbs (5.8 kg)
EW1050H
WATER& TRASH PUMP ACCESSORIES
Description
Size
For Model (s)
Part No.
PVC Suction Hoses
(Non-Collapsible)
1" x 20'
EW120R, EW1050H
123048-A
2" x 20' (Includes Male / Female Fittings)
EW220R, EW2050H
123042-A
3" x 20' (Includes Male / Female Fittings)
EW320R, EW320TR, EW3050H
123043-A
PVC Discharge Hoses
(Collapsible)
1" x 25'
EW120R, EW1050H
123049-A
1" x 50'
128049-A
2" x 50' (Includes Male / Female Fittings)
EW220R, EW2050H
123045-A
3" x 50' (Includes Male / Female Fittings)
EW320R, EW320TR, EW3050H
123046-A
Replacement Gaskets for
Female Fittings
2"
EW220R, EW2050H
421002-A
3"
EW320R, EW320TR, EW3050H
421003-A
Strainer
1"
EW120R
480-02550-29
EW1050H
ME01689268
2"
EW220R, EW2050H
480-05050-29
3"
EW320R, EW320TR
480-08310-33
Tool Kit
-
EW120R
5929002000
EW220R, EW2050H, EW320R, EW320TR 277-90301-H0
Spanner Wrench
2" Hose
EW220R, EW2050H
781001-A
3" Hose
EW320R, EW320TR, EW3050H
781002-A
DFL651FZ
High Torque and High Accuracy with Fastest In-Class Fastening Speed
• Precise torque control consistently delivers repeatability of +/- 10%
• Programmable speed control enables user to control speed of hard or soft joints or production time
using USB connection
• Fastest in-class rotational speed for reduced fastening time
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing /
production
applications
• Battery capacity
warning light
indicates ideal time to
recharge battery
3/8" Square Drive Precise High Torque Angle Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacity (Driving Shank)
Square
3/8"
No Load Speed
80 - 200 RPM
Fastening Torque
25 - 65 Nm. (220 - 580 in./lbs)
Width
2-15/16" (75 mm)
Height (With Battery)
4-9/16" (116 mm)
Length (With Battery)
23-5/8" (600 mm)
Net Weight
4.7 lbs (2.1 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately.
TorqueAdjustmentTool (765027-4),
USB Cable (661432-2)
Programmable
Speed Control,
Reversible
Anti-Kick Back Attachment
197045-8
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications
(Sold Separately)
BFT041RZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
TorqueAdjustmentTool (765027-4)
Bluetooth
®
Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers
repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque
and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to withstand high volume
assembly processes
1/4" Torque Tracer Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4"
No Load Speed
800 RPM
Fastening Torque
1 - 4 Nm. (8.9 - 35 in./lbs)
Width
2-13/16" (72 mm)
Height (With Battery)
10-1/2" (266 mm)
Length
7-1/2" (191 mm)
Net Weight
2.2 lbs (1.0 kg)
Reversible
