218 / 220
BFH120FRAE
BFH040FRAE
Includes:
Torque
Adjustment
Tool
MANUFACTURING&ASSEMBLY
makita.ca
216
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
BFH120FRAE
STANDARD EQUIPMENT INCLUDES:
Two 12V (2.0Ah) MAKSTAR Batteries
(193928-0), Charger (DC18RA), Steel Carrying Case (183664-6),TorqueAdjustmentTool (765027-4)
• Precise torque control consistently delivers repeatability of +/- 10%
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4" (6.4 mm)
No Load Speed
400 RPM
Fastening Torque
5.0 - 12.0 Nm.
(44 - 106 in./lbs)
Width
2-3/16" (55.5 mm)
Height (With Battery) 10-15/32" (266 mm)
Length (With Battery)
7-7/8" (200 mm)
Net Weight
3.3 lbs (1.3 kg)
Reversible
BFH040RAE
STANDARD EQUIPMENT INCLUDES:
Two 12V (2.0Ah) MAKSTAR Batteries
(193928-0), Charger (DC18RA), Steel Carrying Case (183664-6),TorqueAdjustmentTool (765027-4)
• Precise torque control consistently delivers repeatability of +/- 10%
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
1/4" Hazardous Location Screwdriver
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4" (6.4 mm)
No Load Speed
400 RPM
Fastening Torque
0.8 - 4.5 Nm.
(7 - 40 in./lbs)
Width
2-3/16" (71 mm)
Height (With Battery) 10-15/32" (266 mm)
Length (With Battery)
7-7/8" (200 mm)
Net Weight
3.3 lbs (1.3 kg)
Reversible
1/4" Hazardous Location Screwdriver
HAZLOC Series Tools are the only Cordless Power Tools in the world certified for use in
a Class I Division 2 (group A – D) environment as outlined in UL1604 standard.
Class I:
Specifies that ignitable gases, vapours or liquids exist.
Division 2:
Specifies that concentrations of flammable gases, vapours or liquids are not likely to exist under normal
operating conditions but likely to exist under abnormal conditions.
For Battery and Charger Compatibility
please refer to pages 59–61
