EBH341U
STANDARD EQUIPMENT INCLUDES:
10"StarBlade(B-14124),Bump&FeedTrimmerHead(B-05131),ProtectiveGuard(452259-9),TrimmerHeadProtectiveGuardAttachment(135398-7),
BoxWrench16-17(783013-3),HexWrenchM4(783202-0),HexWrenchM5(783217-1),ShoulderHarness(122906-3),EngineOilSet100cc,
StarterRope(444018-5),SparkPlug(168534-0),ToolCover(450573-7),AccessoryBag(831304-7)
Save The Cost Of The Brush Cutter With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be
used on any angles and slopes
• Heavy duty solid steel straight shaft
• Clean exhaust emissions and lower fuel consumption
• Equipped with ˝Swivel System˝ U-handle for maximum operator comfort
• 40% less fuel consumption compared to 2-stroke equivalent
Low Vibration, Extreme
Fuel Cost Savings
10˝ / 33.5 cc 4 Stroke Brush Cutter
SPECIFICATIONS
Cutting Width:
10˝ With Blade
16˝ With Line Head
Displacement
33.5 cc
Maximum Engine Power 1.07 Kw / 1.44 H.P.
Carburetor
Diaphragm Type
Ignition System
Electronic
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.65 L
Oil Tank Capacity
0.1 L
4-Stroke Crank Case oil
10W-30
Overall Length
71-1/4˝ (1,810 mm)
Dry Weight
15.7 lbs. (7.1 kg)
EBH253L
STANDARD EQUIPMENT INCLUDES:
Trimmer HeadAssy (B-05125),Protective Guard (452260-4),Trimmer Head Protective GuardAttachment (135398-7), BoxWrench 16-17
(783013-3),HexWrench M4 (783202-0), Hex Wrench M5 (783217-7), Shoulder Harness (125516-5), Engine Oil Set 80cc, Starter Rope
(444020-8), Spark Plug (168534-0),Accessory Bag (831304-7)
Save The Cost Of The Trimmer With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be
used on any angles and slopes
• Anti-vibration system for fatigue free use
• Clean exhaust emissions and lower fuel consumption
• 40% less fuel consumption compared to 2-stroke equivalent
Quiet, Low Vibration, Extreme
Fuel Cost Savings
16˝ / 24.5 cc 4 Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
16˝
Displacement
24.5 cc
Maximum Engine Power 0.71 Kw / 0.97 H.P.
Carburator
Diaphram Type
Ignition System
Electronic
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5 L
Oil Tank Capacity
0.08 L
4-Stroke Crank Case Oil
10W-30
Overall Length
69-3/4˝ (1,770 mm)
Dry Weight
11.5 lbs. ( 5.2 kg)
ER2550LH
STANDARD EQUIPMENT INCLUDES:
CutterAssy (122980-1), Protective Guard (141511-7), Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Engine Oil Set 80cc,
Starter Rope (444019-3),Accessory Bag (831304-7)
Makita Mini 4-Stroke Series Curved Shaft Trimmer For Professional Use
• Professional series flexible shaft for maximum durability and minimum vibration
• Wide trigger control and soft grip for comfortable operation
• Primer bulb and choke for easy starting
• Durable nylon string trimmer head
• Outstanding power to weight ratio
16-1/4˝ / 24.5 cc 4 Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
16-1/4˝
Displacement
24.5 cc
Maximum Engine Power 0.71 Kw / 0.97 H.P.
Carburator
Diaphram Type
Ignition System
Electronic
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5 L
Oil Tank Capacity
0.08 L
4-Stroke Crank Case Oil
10W-30
Overall Length
64˝ (1,623 mm)
Dry Weight
10.8 lbs. (4.9 kg)
EBH253U
STANDARD EQUIPMENT INCLUDES:
9" Star Blade (B-14118), BandAssy (122906-3), Box Driver 16-17 (783013-3), Hex Wrench M4 (783202-0), Hex Wrench M5 (783217-7),
Tool Cover (450573-7), Engine Oil Set 80cc,Accessory Bag (831304-7)
Save The Cost Of The Brush Cutter With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be used
on any angles and slopes
• Anti-vibration system for fatigue free use
• Clean exhaust emissions and lower fuel consumption
• Easy starting
• 40% less fuel consumption compared to 2-stroke equivalent
Quiet, Low Vibration,
Extreme Fuel Cost Savings
9˝ / 24.5 cc 4 Stroke Brush Cutter
SPECIFICATIONS
Cutting Width
9˝
Displacement
24.5 cc
Maximum Engine Power 0.71 Kw / 0.97 H.P.
Carburator
Diaphram Type
Ignition System
Electronic
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5L
Oil Tank Capacity
0.08L
4-Stroke Crank Case Oil
10W-30
Overall Length
69-3/4˝ (1,770 mm)
Dry Weight
13.0 lbs. (5.9 kg)
STANDARD EQUIPMENT INCLUDES:
ProtectorAssy (DA00000145), Protector (DA00000147),Trimmer Head (DA00000454), BandAssembly (DA00000456),
Socket Wrench M5 (DA00000457),Tool Kit (DA00000458)
Compliant With EPA Phase 2, EU Stage 2 Exhaust Emissions Regulations
• Wide trigger control and soft grip for comfortable operation
• Primer bulb and choke for easy starting
• Durable nylon string trimmer head
9˝ / 25.7 cc 2 Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
9˝ (228 mm)
Displacement
25.7cc
Maximum Engine Power
0.83 Kw / 1.15 HP
Carburator
Diaphram Type
Ignition System
Recoil
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
0.6L
Oil Tank Capacity
(unavailable)
Overall Length
69-3/4˝ (1,770 mm)
Dry Weight
10.8 lbs (4.9 kg)
EM2600L
Professional Use
HRU01ZX2
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
CutterAssembly
(126183-9), Protective Guard (195959-5),Tool Kit (195960-0), Direct Connect Battery Convertor BCV02 (195850-7)
Low Noise Level And Zero Emissions
• Brushless DC Motor with high power to weight and size ratio
• Battery Power Warning light indicates approximate remaining battery power
• Motor Indicator Warning Light indicates current limiter has been activated
• Current Limiter prevents motor burnout caused by overheating
• Electric Brake for increased operator safety
• Variable Speed Settings allow operator to adjust cutting speed based on
materials or application
• 11-3/4˝ Cutting Path (using standard equipment string trimmer head)
• Well Balanced design with Cushioned Rubber Rear Grip and Front Handle, with Shoulder Strap
for Superior Ergonomic Comfort
• Includes BCV02 18V to 36V Li-Ion Battery Converter enabling use with 2 x 18V Li-Ion BL1830 Batteries
11-3/4˝ / 36V Cordless Curved Shaft Line Trimmer
Electric Brake, Variable Speed,
Reversible
BCV02
SPECIFICATIONS
Battery Capacities:
36V (2.6 Ah) Li-Ion
Two 18V (3.0 Ah) Li-Ion
Cutting Width
11-3/4˝ (300 mm)
No Load Speed:
High
0 - 7,000 RPM
Low
0 - 5,100 RPM
Dimensions (L x W x H)
67-3/4˝ x 11-5/8˝ x 16-1/2˝
(1,720 mm x 295 mm x 420 mm)
Net Weight
8.4 lbs (3.8 kg)
