HAMMERS
makita.ca
84
STANDARD EQUIPMENT INCLUDES:
Straight Side Handle (158131-0), Bit Grease (194683-7), Depth Gauge (321248-4), Plastic Carrying Case (824798-3)
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
Variable Speed / Reversible
1-9/16˝ Rotary Hammer
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
1-9/16˝ (40 mm)
Concrete (Core Bit)
4-1/8˝ (105 mm)
No Load Speed
680 RPM
Blows Per Minute
2,500 BPM
Impact Energy
6.2 J (4.6 ft.lbs.)
AMPS (120V)
10.0 A
Overall Length
18˝ (458 mm)
Net Weight
14.6 lbs (6.6 kg)
HR4002
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),StraightSideHandle(135209-6),D-StyleSideHandle(134890-0),CleaningCloth(443122-7),PlasticCarryingCase(154677-4)
SDS-MAX Shank
Hammer & Rotation / Hammer Only
Locking Slide Switch For Chiselling Applications
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
Constant Speed Control,
Variable Speed, Soft Start
1-9/16˝ Rotary Hammer
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
1-9/16˝ (40 mm)
Concrete (Core Bit)
4-1/8˝ (105 mm)
No Load Speed
235 - 480 RPM
Blows Per Minute
1,350 - 2,750 BPM
Impact Energy
9.5 J (7.0 ft. lbs.)
AMPS (120V)
11.0 A
Overall Length
18-1/2˝ (468 mm)
Net Weight
14.8 lbs. (6.7 kg)
HR4010C
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Incorporates both trigger and locking switches for ease of operation in intermittent drilling
and prolonged demoltion applications
• Torque limiter stops bit rotation if bit jams for increased operator safety and tool protection
• Soft start feature gradually increases speed to eliminate start up shock
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
1-9/16˝ (40 mm)
Concrete (Core Bit)
4-1/8˝ (105 mm)
No Load Speed
250 - 500 RPM
Blows Per Minute
1,450 - 2,900 BPM
Impact Energy
8.0 J (5.9 ft.lbs)
AMPS (120V)
11.0 A
Overall Length
18-11/16˝ (479 mm)
Net Weight
15.1 lbs (6.8 kg)
STANDARD EQUIPMENT INCLUDES:
Side Grip (123138-5), Side Handle (196792-8),
Cleaning Cloth (443122-7), Depth Gauge (331955-1),
Plastic Carrying Case (141977-1)
HR4013C
STANDARD EQUIPMENT INCLUDES:
Side Grip (123138-5), Side Handle (196792-8),
Cleaning Cloth (443122-7), Depth Gauge (331955-1),
Depth Gauge B (123066-4), Dust Cover (162356-0),
2 ea. Dust Cap (424472-9), 2 ea. Joint (453115-6),
2 ea. Bellows (453118-0), Joint 25 (453674-0),
Hose Holder C (454809-6),
Plastic Carrying Case (196531-6)
HR4013CV
with Dust Extraction Attachment
HR4013C, HR4013CV
1-3/4˝ Rotary Hammers
Constant Speed Control, Variable Speed, Soft Start
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• 24 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
STANDARD EQUIPMENT INCLUDES:
Bit Grease (194683-7), Side Handle (135197-7),
Depth Gauge(321248-4),
Plastic Carrying Case (824825-6)
HR3210C
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),SideHandle(135197-7),
DepthGauge(321248-4),
QuickChangeDrillChuck(194568-7),
PlasticCarryingCase(824825-6)
HR3201FCT
HR3210C, HR3210FCT
1-4˝ Rotary Hammers
Constant Speed Control,
Variable Speed,
Soft Start
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete (TCT)
1-1/4˝ (32 mm)
Concrete (Core Bit)
3-1/2˝ (90 mm)
No Load Speed
315 - 630 RPM
Blows Per Minute
1,650 - 3,300 BPM
Impact Energy
5.5 J (4.1 ft. lbs.)
AMPS (120V)
8.2 A
HR3210C:
Overall Length
15-5/8˝ (398 mm)
Net Weight
11.5 lbs. (5.2 kg)
HR3210FCT:
Overall Length (with SDS-PLUS Chuck) 16-3/4˝ (424 mm)
Net Weight
11.9 lbs. (5.4 kg)
With
Quick Change
Drill Chuck
194568-7
