Electric
Power Tools
makita.ca
87
STANDARD EQUIPMENT INCLUDES:
1/2˝ Drill Chuck & Key Set (193067-6), Side Handle (135302-6), Depth Gauge (342219-0), Plastic Carrying Case (824650-5)
Hammer & Rotation / Rotation Only
• Improved Motor Durability with Machined Metal Gearing
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Industrial Aluminum Gear Housing for durability
• Industrial Strength Keyed Chuck for durability
• 1/2˝ Chuck will accept 3/4˝ concrete bits with 1/2˝ reduced shank
• 360° Side Handle
Variable 2-Speed, Reversible
3/4˝ Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete
3/4˝ (20 mm)
Steel
1/2˝ (13 mm)
Wood
1-9/16˝ (40 mm)
No Load Speed:
Low
0 - 900 RPM
High
0 - 2,300 RPM
Blows Per Minute:
Low
0 - 18,000 BPM
High
0 - 46,000 BPM
AMPS (120V)
6.0 A
Overall Length
13-3/4˝ (350 mm)
Net Weight
6.4 lbs. (2.9 kg)
HP2050H
STANDARD EQUIPMENT INCLUDES:
1/2˝DrillChuck(192877-8),SideHandle(152491-2),ChuckKey(763432-9),DepthGauge(321220-6),PlasticCarryingCase(824700-6)
Hammer & Rotation / Rotation Only
• Lock-On Button for easy and comfortable operation during periods of prolonged use
• Depth Setting Rod for easier drilling of accurate hole depths
• Side Handle can be positioned on left or right side of tool
1/2˝ Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete
Low -1/2˝ (13 mm), High - 1/2˝ (13 mm)
Steel
Low -1/2˝ (13 mm), High -1/4˝ (6 mm)
Wood
Low -1-1/8˝ (30 mm), High -3/4˝ (18 mm)
No Load Speed:
Low
0 - 800 RPM
High
0 - 2,000 RPM
Blows Per Minute:
Low
0 - 8,800 BPM
High
0 - 22,000 BPM
AMPS (120V)
4.5 A
Net Weight
5.3 lbs. (2.4 kg)
NHP1310
STANDARD EQUIPMENT INCLUDES:
Keyless Drill Chuck (194073-4), Side Handle (135302-6), Depth Gauge (324219-0), Plastic Carrying Case (824811-7)
Ideal For Small Self Anchoring Concrete Screws
Hammer & Rotation / Rotation Only
• Lock-On Button for easy comfortable operation during prolonged periods of use
• 1/2˝ Keyless Chuck will accept 5/8˝ concrete bits with 1/2˝ reduced shank
• 360° Swivel Side Handle
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
5/8˝ Hammer Drill Kit
SPECIFICATIONS
Maximum Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
1-3/16˝ (30 mm)
No Load Speed
0 - 2,800 RPM
Impacts Per Minute
0 - 44,800 IPM
AMPS (120V)
6.0 A
Overall Length
11-7/8˝ (303 mm)
Net Weight
4.4 lbs. (2.0 kg)
HP1641K
STANDARD EQUIPMENT INCLUDES:
Keyless Drill Chuck (194073-4), Side Handle (153503-4), Plastic Carrying Case (824811-7)
Ideal For Small Self Anchoring Concrete Screws
Hammer & Rotation / Rotation Only
• Industrial Aluminum Gear Housing for durability and long tool life
• Lock-On Button for easy comfortable operation during prolonged periods of use
• 1/2˝ Keyless Chuck will accept 5/8˝ concrete bits with 1/2˝ reduced shank
• 360° Swivel Side Handle
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
5/8˝ Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
1-3/16˝ (30 mm)
No Load Speed
0 - 3,200 RPM
Impacts Per Minute
0 - 48,000 IPM
AMPS (120V)
6.2 A
Overall Length
11-5/8˝ (296 mm)
Net Weight
4.4 lbs. (2.0 kg)
HP1631K
Variable Speed, Reversible
• Auxiliary Planing Base and Front Roller enables planing to a
consistent depth (PC5001C Only)
• Electronic Speed Control maintains constant speed
under heavy load
• Soft Start feature gradually increases speed to eliminate
start up shock
• Electronic Current Limiter eliminates motor burnout due
to current overload
• Anti-Restart feature prevents tool from operating if it is plugged
in when locked in the on position
• LED Light indicates active power supply and activation of
Anti-Restart feature
• Easy to Operate Larger Trigger Switch with Lock-On feature
• Removable Front Dust Cap enables operator to plane flush
to walls and corners
SPECIFICATIONS
Wheel Diameter
5˝ (125 mm)
Wheel Type
Offset Diamond
Hole Diameter
7/8˝ (22.3 mm)
No Load Speed
10,000 RPM
AMPS (120V)
10.0 A
Cord length
16.4 ft. (5.0 m)
PC5000C:
Overall Length 17-1/8˝ (437 mm)
PC5000C:
Net Weight
8.8 lbs. (4.0 kg)
PC5001C:
Overall Length 18-13/16˝ (479 mm)
PC5001C:
Net Weight
11.2 lbs. (5.1 kg)
STANDARD EQUIPMENT INCLUDES:
Loop Handle (273529-1), 5˝ Offset Finish Diamond
Wheel (A-94998), Dust BagAssembly (122853-8),
Wrench Holder (410047-0), Hex Wrench 5 (783203-8),
Lock Nut Wrench 28 (782425-7),
Steel Carrying Case (140073-2)
PC5001C
PC5000C, PC5001C
5˝ Concrete Planers
STANDARD EQUIPMENT INCLUDES:
Loop Handle (416256-9), 5˝ Offset Coarse Diamond
Wheel (A-95009), Dust BagAssembly (122853-8),
Wrench Holder (410047-0), Hex Wrench 5 (783203-8),
Lock Nut Wrench 28 (782425-7),
Steel Carrying Case (140073-2)
PC5000C
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
CONCRETE PLANER ACCESSORIES
Description
Notes
For Model(s)
Part No.
Replacement Front Dust Cap Brush
Rinses Clean with Water
PC5000C
PC5001C
743340-0
Replacement Main Dust Cap Brush
743341-8
5" Diamond Cup Wheel (7/8" Arbor)
Continuous Rim (Finish)
A-94998
Segmented Rim - Double Row (Coarse)
A-95009
