SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for
greatly reduced transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator safety and tool protection
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• 16 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
2˝ (52 mm)
Concrete (Core Bit)
6-1/4˝ (160 mm)
No Load Speed
130 - 260 RPM
Blows Per Minute
1,075 - 2,150 BPM
Impact Energy
20 J (15 ft.lbs.)
AMPS (120V)
15.0 A
Overall Length
23-1/2˝ (599 mm)
Net Weight
26.9 lbs. (12.2 kg)
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),D-StyleSideHandle(135269-8),
StraightSideHandle(135380-6),
CleaningCloth(443122-7),DepthGauge(321248-4),
PlasticCarryingCase(196188-3)
HR5211C
Locking Slide Switch For ChisellingApplications
(HR5210C Only)
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),D-StyleSideHandle(135269-8),
StraightSideHandle(135380-6),
CleaningCloth(443122-7),DepthGauge(321248-4),
PlasticCarryingCase(196187-5)
HR5210C
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator safety and tool protection
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• 16 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
1-3/4˝ (45 mm)
Concrete (Core Bit)
5˝ (125 mm)
No Load Speed
130 - 280 RPM
Blows Per Minute
1,250 - 2,750 BPM
Impact Energy
12.5 J (9.2 ft. lbs.)
AMPS (120V)
13.5 A
Overall Length
18˝ (458 mm)
Net Weight
19.8 lbs. (9.0 kg)
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),StraightSideHandle(158131-0),
D-StyleSideHandle(134890-0),
CleaningCloth(443122-7),DepthGauge(321248-4),
Plastic Carrying Case (196188-3)
HR4511C
Locking Slide Switch For ChisellingApplications
(HR4510C Only)
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),StraightSideHandle(158131-0),
D-StyleSideHandle(134890-0),
CleaningCloth(443122-7),DepthGauge(321248-4),
Plastic Carrying Case (196187-5)
HR4510C
Locking Slide Switch
HR5211C, HR5210C
2˝ Rotary Hammers
HR4511C, HR4510C
1-3/4˝ Rotary Hammers
Variable Speed, Constant Speed Control, Soft Start
Variable Speed, Constant Speed Control, Soft Start
SDS-MAX Shank
Hammer & Rotation / Hammer Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of
tool for greatly reduced transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator
safety and tool protection
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on
materials or application
• 16 Angle Bit Positions enable chisels to be positioned at optimum
angle of operation
SPECIFICATIONS
Bit Type
SDS-MAX
Maximum Capacities:
Concrete (TCT)
1-3/4˝ (45 mm)
Concrete (Core Bit)
5˝ (125 mm)
No Load Speed
130 - 280 RPM
Blows Per Minute
1,250 - 2,750 BPM
Impact Energy
12.5 J (9.2 ft. lbs.)
AMPS (120V)
13.5 A
Overall Length
18˝ (458 mm)
Net Weight
19.6 lbs. (8.9 kg)
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),D-StyleSideHandle(135531-1),
CleaningCloth(443122-7),
DustExtractionAttachment(196074-8),
PlasticCarryingCase(196192-2)
HR4511CV
Locking Slide Switch For ChisellingApplications
(HR4510CV Only)
STANDARD EQUIPMENT INCLUDES:
BitGrease(194683-7),D-StyleSideHandle(135531-1),
CleaningCloth(443122-7),
DustExtractionAttachment(196074-8),
PlasticCarryingCase(196191-4)
HR4510CV
HR4511CV, HR4510CV
1-3/4
˝
Rotary Hammers with Dust Extraction Attachment
Variable Speed, Constant Speed Control, Soft Start
