STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6), Depth Gauge (324219-0), Plastic Carrying Case (824695-3)
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• High Durability design with Zig-Zag Armature Varnish, Enhanced Sealing, Improved Impact Bolt and
Impact Reducing Cushion Ring
• Rubber Housing Bumper protects mode selector switch and gear housing from damage
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• Ergonomic Soft Rubber D-Handle for vibration absorption and comfortable operation
Variable Speed, Reversible
1˝ Rotary Hammer
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
1˝ (25 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
Impact Energy
2.7 J (2.0 ft. lbs.)
AMPS (120V)
7.0 A
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,500 BPM
Overall Length
16-7/8˝ (429 mm)
Net Weight
6.6 lbs. (3.0 kg)
HR2475
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly
reduced transmission to operator
• Torque Limiter stops bit rotation if bit jams for increased operator safety and
enhanced tool protection
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,200 RPM
Blows Per Minute
0 - 4,600 BPM
Impact Energy
2.9 J (2.1 ft. lbs.)
AMPS (120V)
7.0 A
HR2611F:
Overall Length
14-1/4˝ (361 mm)
Net Weight
7.3 lbs. (3.3kg)
HR2611FT:
Overall Length (with SDS-PLUS Chuck)
15-1/8˝ (385 mm)
Net Weight
7.5 lbs. (3.4 kg)
With Quick Change Drill Chuck
(HR2611FT Only)
STANDARD EQUIPMENT INCLUDES:
Side Handle (122878-2), Depth Gauge (331886-4),
Quick Change Drill Chuck (194079-2),
Plastic Carrying Case (140403-7)
HR2611FT
STANDARD EQUIPMENT INCLUDES:
Side Handle (122878-2), Depth Gauge (331886-4),
Plastic Carrying Case (140401-1)
HR2611F
HR2611F, HR2611FT
1˝ Rotary Hammers
Variable Speed
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Side Handle (122878-2), Depth Gauge (331886-4), Plastic Carrying Case (140401-1)
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Anti-Vibration Technology
TM
(AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• High durability design with zig-zag armature varnish, enhanced sealing, improved impact bolt
and impact reducing cushion ring
• Retractable sky hook allows tool to be hung on rafters, pipes or scaffolding
• Improved bit guide for increased bit stability during drilling applications
• Re-located operating mode lever for increased protection and durability
Variable Speed,
Reversible
1˝ Rotary Hammer
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,500 BPM
Impact Energy
2.4 J (1.8 ft. lbs)
AMPS (120V)
8.0 A
Overall Length
16-5/8˝ (422 mm)
Net Weight
6.8 lbs (3.1 kg)
HR2621
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Compact L-Shaped Motor Housing for high maneuverability and better handling
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Vibration Absorbing Handle with Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
• Rubber Bumper protects mode selector switch from damage
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6),
Depth Gauge (324219-0),
Plastic Carrying Case (824789-4)
HR2811F
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6),
Depth Gauge (324219-0),
Quick Change Drill Chuck (194079-2),
Plastic Carrying Case (824789-4)
HR2811FT
HR2811F, HR2811FT
1-1/8˝ Rotary Hammers
Variable Speed,
Reversible
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
1-1/8˝ (28 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,500 BPM
Impact Energy
2.9 J (2.1 ft. lbs)
AMPS (120V)
7.0 A
HR2811F:
Overall Length
12-5/8˝ (320 mm)
Net Weight
7.7 lbs. (3.5 kg)
HR2811FT:
Overall Length (with SDS-PLUS Chuck) 13-5/8˝ (345 mm)
Net Weight
7.9 lbs. (3.6 kg)
With
Quick Change
Drill Chuck
194079-2
With
Quick Change
Drill Chuck
194079-2
