HAMMERS
makita.ca
86
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6), Depth Gauge (415486-9), Plastic Carrying Case (824650-5)
SDS-PLUS Shank, Makita's Smallest, Lightest Weight Rotary Hammer
Hammer & Rotation / Rotation Only
• Ideal for small concrete screws and anchors in overhead applications
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Reverse Rotation System using Brush Holder Unit provides the same amount of power in forward and
reverse and extends life of carbon brushes
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• One-Touch Sliding Chuck for easy bit installation and removal
• LED Light illuminates drilling position
Variable Speed, Reversible
11/16˝ Rotary Hammer
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
11/16˝ (18 mm)
Steel
1/2˝ (13 mm)
Wood
15/16˝ (24 mm)
No Load Speed
0 – 1,500 RPM
Blows Per Minute
0 – 5,000 BPM
Impact Energy
1.2 J (0.9 ft. lbs.)
AMPS (120V)
3.9 A
Overall Length
10-7/8˝ (279 mm)
Net Weight
4.2 lbs. (1.9 kg)
HR1830F
STANDARD EQUIPMENT INCLUDES:
1/2˝ Drill Chuck (192877-8), Chuck Key (763432-9), Side Handle (122428-3), Depth Gauge (321059-7), Plastic Carrying Case (824608-4)
Makita’s Most Popular 3/4˝ Hammer Drill
Hammer & Rotation / Rotation Only
• Industrial Aluminum Gear Housing for durability
• 1/2˝ Chuck will accept 3/4˝ concrete bits with 1/2˝ reduced shank
• Depth Setting Rod for easier drilling of accurate hole depths
• 360° Swivel Side Handle
Variable 2-Speed, Reversible
3/4˝ Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete
3/4˝ (20 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/2˝ (40 mm)
No Load Speed:
Low
0 - 900 RPM
High
0 - 2,300 RPM
Blows Per Minute:
Low
0 - 18,000 BPM
High
0 - 46,000 BPM
AMPS (120V)
6.0 A
Overall Length
13-3/4˝ (350 mm)
Net Weight
6.4 lbs. (2.9 kg)
HP2010N
STANDARD EQUIPMENT INCLUDES:
Dust Bag (122708-7), Dust Cap (421727-3), Side Handle (135302-6), Plastic Carrying Case (824729-2) (Shown with Optional Bit)
SDS-Plus Shank, Built-In Dust Collection System
Hammer & Rotation / Hammer Only / Rotation Only
• Dust Collection System especially suited for operation in Hospitals, Schools and other job sites
where dust collection is mandatory
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
Variable Speed, Reversible,
With Dust Collector
1˝ Rotary Hammer
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
1˝ (25 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,000 RPM
Blows Per Minute
0 - 4,500 BPM
Impact Energy
2.2 J (1.6 ft. lbs.)
AMPS (120V)
6.7 A
Overall Length
16˝ (407 mm)
Net Weight
7.1 lbs. (3.2 kg)
HR2432
• Double sided impeller and enlarged blower outlet provides increased air volume for maximum
performance and efficiency
• Self standing design allows tool to stand upright for use in stationary applications
• Top and rear handle design enables comfortable positioning for optimal jobsite maneuverability
• Converts quickly and easily between blower and vacuum modes
• Variable speed trigger and dial enables operator to adjust blower or suction speed based
on the material or application
• Lock-on button for operator convenience during periods of prolonged use
• Ergonomic soft rubber grip design for comfortable operation
Anti-Static Design
Blower / Vacuum
SPECIFICATIONS
Max. Air Volume 145 CFM (4.1 m
3
/min)
Max. Air Pressure (Water Column)
5.7kPa (580 mm)
Max. Air Flow (End Of Nozzle)
203 MPH (91 m/sec)
No Load Speed
0 - 16,000 RPM
AMPS (120V)
6.8 A
Overall Length
18 -7/8” ( 479 mm)
Dry Weight
4.3 lbs (2.0 kg)
UB1103
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and
enhanced tool protection
• High Durability design with “Zig-Zag” Armature Varnish, Enhanced Sealing, Improved
Impact Bolt and Impact Reducing
Cushion Ring
SPECIFICATIONS
Bit Type
SDS-PLUS
Maximum Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,500 BPM
Impact Energy
2.7 J (1.99 ft. lbs.)
AMPS (120V)
6.7 A
HR2470FT:
Overall Length (with SDS-PLUS Chuck) 15-1/2˝ (394 mm)
Overall Length (with Drill Chuck)
17˝ (431 mm)
Net Weight
6.6 lbs. (3.0 kg)
HR2470F:
Overall Length
14-1/2˝ (370 mm)
Net Weight
6.4 lbs. (2.9 kg)
With Quick Change Drill Chuck
(HR2470FT Only)
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6), Depth Gauge (324219-0),
Plastic Carrying Case (824799-1),
Quick Change Drill Chuck (194079-2)
HR2470FT
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6), Depth Gauge (324219-0),
Plastic Carrying Case (824799-1)
HR2470F
HR2470FT, HR2470F
15/16˝ Rotary Hammers
Variable Speed, Reversible
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Optional Long Nozzle with
Curved End available
(Part No. 196729-5)
With
Quick Change
Drill Chuck
194079-2
