DTL061F
STANDARD EQUIPMENT INCLUDES:
DTL061F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Phillips Bit 2-45 (784202-3), Hook (324705-1)
DTL061Z:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-45 (784202-3), Hook (324705-1)
Compact Angled Head For Easy Access In Confined Spaces
• 2-1/8˝ Head Height ideal for driving fasteners in confined spaces
• Machined Aluminum Head for added durability
• 360° Rotatable Head enables operation from optimum angle
• Conveniently located Forward / Reverse Switch
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
1/4˝ Hex Shank, Variable Speed, Reversible
1/4˝ Cordless Angle Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 2,000 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Torque 531 in. lbs. (60 Nm)
Overall Length
15-1/4˝ (387 mm)
Net Weight
3.8 lbs. (1.7 kg)
DTL061Z
2-1/8˝
DTL063F
STANDARD EQUIPMENT INCLUDES:
DTL063F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Hook (324705-1)
DTL063Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (324705-1)
Compact Angled Head For Easy Access In Confined Spaces
• 2-1/8˝ Head Height ideal for driving fasteners in confined spaces
• Machined Aluminum Head for added durability
• 360° Rotatable Head enables operation from optimum angle
• Conveniently located Forward / Reverse Switch
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3/8˝ Square Drive, Variable Speed, Reversible
3/8˝ Cordless Angle Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
3/8˝ Square
No Load Speed
0 - 2,000 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Torque 530 in. lbs. (60 Nm)
Overall Length
15-1/4˝ (387mm)
Net Weight
3.8 lbs. (1.7 kg)
DTL063Z
2-1/8˝
STANDARD EQUIPMENT INCLUDES:
DDA350RFE
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), Side Handle (153489-2),
Chuck Key Holder (450688-0), Chuck Key(763415-9), Plastic Carrying Case(824851-5)
DDA350F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Side Handle (153489-2), Chuck Key Holder (450688-0), Chuck Key (763415-9)
DDA350Z:
ToolOnly.BatteriesandChargerSoldSeparately.
SideHandle(153489-2),ChuckKeyHolder(450688-0),ChuckKey(763415-9)
Compact Design For Optimal Versatility In Confined Spaces
• 2-5/8˝ Head Height ideal for operation in confined spaces
• Industrial Aluminum Gear Housing for increased durability
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
3/8˝ Cordless Angle Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
1˝ (25 mm)
No Load Speed
0 - 1,800 RPM
Overall length
12-3/8˝ (314 mm)
Net Weight
4.0 lbs (1.8 kg)
DDA350RFE
DDA350F
DDA350Z
2-5/8˝
DLS713F
Incorporates Makita's Battery Protection System
Up To 11-3/4˝ Cuts In 2x Material
• Battery Protection System provides Over-Discharge, Temperature and Current Protection for
enhanced performance, battery cycle life and overall battery life
• Dual Sliding Rail Mechanism incorporating 6 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Electric Brake for increased operator safety
• 2 Stage Safety Switch for increased operator safety
7-1/2˝ Cordless Dual Sliding Compound Mitre Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
7-1/2˝ (190 mm)
Arbor
5/8˝ (15.9 mm)
Overall Dimensions (L x W x H)
25-3/4˝ x 17˝ x 17-7/8˝
(699 mm x 430 mm x 454 mm)
Net Weight
27.3 lbs. (12.4 kg)
DLS713Z
STANDARD EQUIPMENT INCLUDES:
DLS713F:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), 7-1/2˝ C.T. Blade 40T(A-90912), Dust Bag (122852-0),
Hex Wrench (783203-8),Triangle Rule (762001-3), Vertical Vice (122571-8), 2 Ea. Holders (322312-4)
DLS713Z:
Tool Only. Batteries and Charger Sold Seperately.
7-1/2˝ C.T. Blade 40T(A-90912), Dust Bag (122852-0),
Hex Wrench (783203-8),Triangle Rule (762001-3), Vertical Vice (122571-8), 2 Ea. Holders (322312-4)
DFS451RFE
STANDARD EQUIPMENT INCLUDES:
DFS451RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Hook (346449-3),
2 Ea. Phillips Bit 2-25 (784211-2), Magnetic Bit Holder (784801-1), Plastic Carrying Case (824978-1)
DFS451F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3),Hook(346449-3),2Ea.PhillipsBit2-25(784211-2),MagneticBitHolder(784801-1)
DFS451Z:
ToolOnly.BatteriesandChargerSoldSeparately.
Hook(346449-3),2Ea.PhillipsBit2-25(784211-2),MagneticBitHolder(784801-1)
Incorporates Makita's Battery Protection System Compact And
Lightweight Pistol-Grip Design
• Battery Protection System provides Over-Discharge, Temperature and Current Protection for
enhanced performance, battery cycle life and overall battery life
• SilentClutchofferssmootherengagementofgearingforhigherdurabilityandincreasedoperationalefficiency
• Variable Speed Trigger allows operator to adjust driving speed based on materials or application
• One Touch Locator enables quick and easy bit changes
• LED Job Light with Afterglow feature
Variable Speed
1/4˝ Cordless Drywall Screwdriver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 4,000 RPM
Overall Length
11-1/8˝ (281 mm)
Net Weight
3.7 lbs. (1.7 kg)
DFS451F
DFS451Z
DFS450RFE
STANDARD EQUIPMENT INCLUDES:
DFS450RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Phillips Bit 2-25 (784211-2),
Magnetic Bit Holder (784801-1), Belt Clip (281220-7), Plastic Carrying Case (824756-9)
DFS450F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Phillips Bit 2-25(784211-2), Magnetic Bit Holder (784801-1), Hook (281220-7)
DFS450Z:
ToolOnly.BatteriesandChargerSoldSeparately.
PhillipsBit2-25(784211-2),MagneticBitHolder(784801-1),BeltClip(281220-7)
Compact And Lightweight Design For Optimal Versatility And Efficiency
• SilentClutchofferssmootherengagementofgearingforhigherdurabilityandincreasedoperationalefficiency
• Compact and Lightweight design for easy handling (Only 10-1/8˝ Long)
• One Touch Locator enables quick and easy bit changes
• LED Light with Afterglow feature
• Conveniently located Forward / Reverse Switch
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Reversible
1/4˝ Cordless Drywall Screwdriver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
4,000 RPM
Overall Length
10 - 1/8˝ (258 mm)
Net Weight
4.2 lbs. (1.9 kg)
DFS450F
DFS450Z
