STANDARD EQUIPMENT INCLUDES:
DPB181RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),
Charger (DC18RC), Bi-Metal Band Saw Blade 18TPI (B-40559),
2 ea. Battery Cover (450128-8), Hex Wrench 4 (783202-0),
Hook (345736-7),Tool Bag (831303-9)
DPB181Z:
Tool Only. Batteries and Charger Sold Separately.
Bi-MetalBandSawBlade18TPI(B-40559),HexWrench4(783202-0),Hook(345736-7),ToolBag(831303-9)
Compact And Lightweight Design Ideal For Confined
Spaces Or Small Diameter Material
• Compact and lightweight design ideal for overhead cutting applications or small diameter pipes,
channel, strut and more!
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• Lock-off button prevents accidental startup
• Ball bearing blade guide provides smooth blade movement
• LED job light with pre-glow feature
Cordless Band Saw
SPECIFICATIONS
Battery
18V Li-Ion
Maximum Capacities:
Round Work Piece Diameter
2-1/2˝ (64 mm)
Square Work Piece
2-1/2˝ x 2-1/2˝ (64 mm x 64 mm)
Blade Speed 630 ft. / min. (3.2 m / sec.)
Overall Length
18-5/8˝ (473 mm)
Net Weight
7.1 lbs (3.2 kg)
DPB181RFE
LED Light
DPB180RFE
STANDARD EQUIPMENT INCLUDES:
DPB180RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Bi-Metal Band Saw Blade 18TPI (792556-A),
Grip (273525-9), Hex Wrench 4 (783202-0), Plastic Carrying Case (824766-6)
DPB180F:
18V(3.0Ah)Li-ionBattery
BL1830(194205-3),Bi-MetalBandSawBlade18TPI(792556-A),Grip(273525-9),HexWrench4(783202-0)
DPB180Z:
ToolOnly.BatteriesandChargerSoldSeparately.
Bi-MetalBandSawBlade18TPI(792556-A),Grip(273525-9),HexWrench4(783202-0)
Well Balanced And Lightweight
• Ideal centre of gravity creates well balanced design for optimum control
• Variable Speed Dial enables operator to set constant speed based on materials or application
• Electronic Current Limiter prevents motor burnout due to overloading
• Warning Light indicates ideal time to recharge battery
• Ball Bearing Blade Guides provide smooth blade movement
• Rubber Bumper protects tool from damage
• LED Light with Afterglow feature
• Accepts standard 1/2˝ x 44-7/8˝ blades
Electronic Current Limiter, LED Light
Cordless Band Saw
SPECIFICATIONS
Battery
18V Li-Ion
Cutting Capacities:
Round Material
4-3/4˝ (120 mm)
Square Material
4-3/4˝ x 4-3/4˝
(120 mm x 120 mm)
Blade Speed
275-530 ft./min.
Overall Length
20-5/8˝ (523 mm)
Net Weight
14.3 lbs. (6.5 kg)
DPB180F
DPB180Z
DPB181Z
STANDARD EQUIPMENT INCLUDES:
DSS610RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),Charger(DC18RC),6-1/2"CircularSawBlade24CT(A-85092),HexWrench
(783203-8),GuideRule(164095-8),PlasticCarryingCase(824757-7)
DSS610F:
18V(3.0Ah)Li-ionBattery
BL1830(194205-3),6-1/2"CircularSawBlade24CT(A-85092),HexWrench(783203-8),GuideRule(164095-8)
DSS610Z:
ToolOnly.BatteriesandChargerSoldSeparately.
6-1/2˝CircularSawBlade24CT(A-85092),HexWrench(783203-8),GuideRule(164095-8)
Compact And Lightweight Design For High Maneuverability
• Blower Feature keeps cutting line free of saw dust
• Electric Brake stops blade immediately for added safety
• High Power Motor for maximum cutting efficiency
• Large Lock-Off Safety Lever prevents accidental start up
• LED Light with Afterglow feature
• Bevel Cuts up to 50°
• Positive Stop at 45° for quick angle setting
Electric Brake, Blower, LED Light
6-1/2˝ Cordless Circular Saw
SPECIFICATIONS
Battery
18V Li-Ion
Blade Diameter
6-1/2˝ (165 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Depth:
0°
2-1/4˝ (57 mm)
45°
1-9/16˝ (40 mm)
No Load Speed
3,700 RPM
Overall Length
13-5/8˝ (346 mm)
Net Weight
7.7 lbs. (3.5 kg)
DSS610RFE
DSS610Z
DSS610F
DSS611RFE
STANDARD EQUIPMENT INCLUDES:
DSS611RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), 6-1/2” C.T. Saw Blade 16T(T-01395),
Hex Wrench (783203-8), Guide Rule (164095-8), Plastic Carrying Case (824757-7)
DSS611F:
18V(3.0Ah)Li-ionBattery
BL1830(194205-3),6-1/2˝C.T.SawBlade16T(T-01395),HexWrench(783203-8),GuideRule(164095-8)
DSS611Z:
ToolOnly.BatteriesandChargerSoldSeparately.
6-1/2˝C.T.SawBlade16T(T-01395),HexWrench(783203-8),GuideRule(164095-8)
• High Power Motor for maximum cutting efficiency
• Large Lock-Off Safety Lever prevents accidental start up
• Bevel Capacity of 50°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
6-1/2˝ Cordless Circular Saw
SPECIFICATIONS
Battery
18V Li-Ion
Blade Diameter
6-1/2˝ (165 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Depth:
0°
2-1/4˝ (57 mm)
45°
1-9/16˝ (40 mm)
50°
1-7/16˝ (36 mm)
No Load Speed
3,700 RPM
Overall Length
13-5/8˝ (347 mm)
Net Weight
6.8 lbs. (3.1 kg)
DSS611F
DSS611Z
STANDARD EQUIPMENT INCLUDES:
DCS550RFE
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), 5-3/8˝ C.T. Saw Blade 30T(A-95037), Charger (DC18RC),
Hex Wrench (783203-8), Safety Goggles (192219-6), Plastic Carrying Case (824802-8)
DCS550F:
18V(3.0Ah)Li-ionBattery
BL1830(194205-3),5-3/8˝C.T.SawBlade30T(A-95037),HexWrench(783203-8),SafetyGoggles(192219-6)
DCS550Z:
ToolOnly.BatteriesandChargerSoldSeparately.
5-3/8˝C.T.SawBlade30T(A-95037),HexWrench(783203-8),SafetyGoggles(192219-6)
Compact & Lightweight With Well Balanced Design
• Designed for cutting channel, corrugated steel, conduit, pipe, sheet metal,
square tubing, angle iron and more
• LED Job Light illuminates cutting area
• Large Lock-Off Safety Lever prevents accidental start up
• Stainless Steel Base Plate
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Electric Brake
5-3/8˝ Cordless Metal Cutting Saw
SPECIFICATIONS
Battery
18V Li-Ion
Blade Diameter
5-3/8˝ (136 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
3,600 RPM
Maximum Cutting Capacity 2˝ (51 mm)
Overall Length
13-3/4˝ (348 mm)
Net Weight
5.7 lbs. (2.6 kg)
DCS550RFE
DCS550F
DCS550Z
STANDARD EQUIPMENT INCLUDES:
DSS501RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), 5-3/8" C.T. Saw Blade 16T(A-94904),
Hex Wrench (783203-8), Guide Rule (164095-8), Plastic Carrying Case (824802-8)
DSS501F:
18V(3.0Ah)Li-ionBattery
BL1830(194205-3), 5-3/8" C.T. Saw Blade 16T(A-94904), Hex Wrench (783203-8),
Guide Rule (164095-8)
DSS501Z:
ToolOnly.BatteriesandChargerSoldSeparately.
5-3/8˝C.T.SawBlade16T(A-94904),HexWrench(783203-8),GuideRule(164095-8)
Compact And Lightweight Design For High Maneuverability
• Blower feature keeps cutting line free of saw dust
• Electric Brake stops blade immediately for added safety
• High Power Motor for maximum cutting efficiency
• Large Lock-Off Safety Lever prevents accidental start up
• LED Job Light with Afterglow feature
• Stainless Steel Base Plate
• Bevel Capacity of 50°
Electric Brake, Blower, LED Light
5-3/8˝ Cordless Circular Saw
SPECIFICATIONS
Battery
18V Li-Ion
Blade Diameter
5-3/8˝ (136 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Depth:
0°
2˝ (51 mm)
45°
1-3/8˝ (35 mm)
No Load Speed
3,600 RPM
Overall Length
14-3/8˝ ( 364 mm)
Net Weight
6.0 lbs. (2.7 kg)
DSS501RFE
DSS501Z
DSS501F
