Electric
Power Tools
makita.ca
81
STANDARD EQUIPMENT INCLUDES:
MakitaLargeShankBullPoint(A-80466),HexWrench5(783203-8),HexWrench6(783204-6),HexWrench10(783207-0),MetalCarryingCase(182714-4)
Makita Large Shank
• Pneumatic Compression System automatically adjusts air in the cylinder to minimize power
loss and deliver unmatched power-to-weight ratio
• Rubber-Ringed Brush Holder cushions vibrations and lengthens life of brushes and armature
• Factory Packed Grease for approximately 200 hours of maintenance free operation
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
39.2 Lbs. Demolition Hammer
SPECIFICATIONS
Bit Type
Makita Large (30 mm Hex)
Blows Per Minute
1,300 BPM
Impact Energy
40.3 J (29.7 ft. lbs.)
AMPS (120V)
13.5 A
Overall Length
25-1/2˝ (647 mm)
Net Weight
39.2 lbs. (17.8 kg)
HM1500
STANDARD EQUIPMENT INCLUDES:
2Ea.1-1/8˝HexShankBullPoint(751420-A),2Ea.1-1/8˝HexShankNarrowChisel(751220-A),HexWrench(783203-8),ToolCart(122010-A)
1-1/8˝ Hex Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Factory grease packed for approximately 200 hours of maintenance free operation
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• LED Power Light indicates active power supply
• Cylindrical Tool Body with high repairability
AC/DC
70 Lbs. Breaker Hammer Kit
HM1810X3
SPECIFICATIONS
Bit Type
1-1/8˝ Hex
Blows Per Minute
1,100 BPM
Impact Energy
63 J (46.5 ft. lbs.)
AMPS (120V)
15.0 A
Overall Length
32-1/2˝ (824 mm)
Net Weight
71.2 lbs. (32.3 kg)
STANDARD EQUIPMENT INCLUDES:
1-1/8˝ Hex Shank Bull Point (751420-A), Plastic Carrying Case (824897-1)
1-1/8˝ Hex Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On / Off Switch for easy continuous use applications
• LED Service Light indicates appropriate time to change carbon brushes
• LED Power Light indicates active power supply
• Extra Long Carbon Brushes for extended service life
Constant Speed Control,
Variable Speed, Soft Start
42 Lbs. Demolition Hammer
SPECIFICATIONS
Bit Type
1-1/8˝ Hex
Blows Per Minute
730 - 1,450 BPM
Impact Energy
34.9 J (25.7 ft. lbs.)
AMPS (120V)
14.0 A
Overall Length
32-1/2˝ (824 mm)
Net Weight
41.9 lbs. (19.0 kg)
HM1317CB
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Maximizing
Power and User
Comfort while
Controlling
Harmful Vibration
Principle of dynamic
vibration absorber
Utilizingmodernearthquakecontroltechnology
Vibration absorption grip for
maximum control
Spring loaded hinged grip
absorbs vibration
Utilized on the following models:
HR3210FC, HR3210FCT, HR4011C,
HR4511C, HR5211C
Hinge
Spring
Makita’s dynamic vibration
absorbing system
By using the inverse relationship
of air pressure between the crankcase
and piston cylinder, the balancer
moves in the opposite direction of
the piston to minimize vibration.
Balancer
Piston
Balancer
Piston
Protect Your Investment
in Tools & People
STANDARD EQUIPMENT INCLUDES:
SDS-MaxBullPoint(751423-A),BitGrease(194683-7),CleaningCloth(443122-7),D-StyleSideHandle(135269-8),PlasticCarryingCase(824908-2)
SDS-MAX Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On / Off Switch for easy continuous use applications
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• LED Service Light indicates appropriate time to change carbon brushes
Constant Speed Control,
Variable Speed, Soft Start
23.8 Lbs. Demolition Hammer
SPECIFICATIONS
Bit Type
SDS-MAX
Blows Per Minute
950 - 1,900 BPM
Impact Energy
25.5 J (18.8 ft. lbs.)
AMPS (120V)
14.0 A
Overall Length
22-3/4˝ (576 mm)
Net Weight
23.8 lbs. (10.8 kg)
HM1213C
