HAMMERS
makita.ca
82
STANDARD EQUIPMENT INCLUDES:
Bit Grease (194683-7), Side Handle (135332-7), Cleaning Cloth (443122-7), Plastic Carrying Case (824904-0)
SDS-MAX Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On / Off Switch for easy continuous use applications
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
Constant Speed Control,
Variable Speed, Soft Start
12.3 Lbs. Demolition Hammer
SPECIFICATIONS
Bit Type
SDS–MAX
Blows Per Minute
1,100 - 2,650 BPM
Impact Energy
11.6 J (8.6 ft. lbs.)
AMPS (120V)
10.0 A
Overall Length
18-3/8˝ (466 mm)
Net Weight
12.3 lbs. (5.6 kg)
HM0871C
STANDARD EQUIPMENT INCLUDES:
SDS-PLUS Scaling Chisel (A-87052), Plastic Carrying Case (824523-2)
SDS-PLUS Shank
• Ideal for removing tile, linoleum, cleaning out mortar or detailed chiseling
• Factory Grease Packed for maintenance free operation
• Variable Speed Dial allows operator to adjust speed based on materials or application
• One-Touch Sliding Chuck for easy bit installation and removal
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
Variable Speed
Power Scraper
SPECIFICATIONS
Bit Type
SDS-PLUS
Blows Per Minute
2,000 - 3,500 BPM
Impact Energy
2.8 J (2.1 ft. lbs.)
AMPS (120V)
5.0 A
Overall Length
18-13/32˝ (468 mm)
Net Weight
7.1 lbs. (3.2 kg)
HK0500
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 4 (783202-0), Side Handle (273472-4), D-Stype Side Handle (134887-9), Plastic Carrying Case (150589-9)
Spline Or 3/4˝ Hex, 21/32˝ Round Shank
Hammer & Rotation / Hammer Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Large Comfortable Grip swivels 360° for easy handling
• Factory Packed Grease for reduced maintenance
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
2˝ Rotary Hammer
SPECIFICATIONS
Bit Type:
Spline Shank
3/4˝ Hex / 21/32˝ Round
Maximum Capacity:
Concrete (TCT)
2˝ (50 mm)
Concrete (Core Bit)
5-7/8˝ (150 mm)
No Load Speed
260 RPM
Blows Per Minute
2,100 BPM
Impact Energy
17 J (12.5 ft. lbs.)
AMPS (120V)
11.0 A
Overall Length
18-3/4˝ (476 mm)
Net Weight
21.8 lbs. (9.9 kg)
HR5000
SDS-PLUS Shank
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Factory Grease Packed for approximately 200 hours of maintenance free operation
• Variable Speed Dial allows operator to adjust speed based on materials or application
• One-Touch Sliding Chuck for easy bit installation and removal
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• Vibration Absorbing Handle with Ergonomic Soft Rubber Grip for vibration absorption
and comfortable operation
• Rear Extension Handle and Wheel Assembly ideal for scraping floor tiles, linoleum, etc.
from a standing position (HK1820L Only)
SPECIFICATIONS
Bit Type
SDS-PLUS
Blows Per Minute
0 - 3,200 BPM
AMPS (120V)
5.0 A
HK1820:
Impact Energy
3.9 J (2.9 ft. lbs.)
Overall Length
13-3/4˝ (351 mm)
GD0800C
Net Weight
7.5 lbs. (3.4 kg)
HK1820L:
Impact Energy
3.7 J (2.7 ft. lbs.)
Overall Length
51.0˝ (1,3 m)
Net Weight
11.7 lbs. (5.3 kg)
HK1820, HK1820L
Power Scrapers
Variable Speed
STANDARD EQUIPMENT INCLUDES:
Cord Hook (158024-1),
Plastic Carrying Case (824789-4)
HK1820
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 5 (783203-8)
(Shown with Optional Scraping BladeAssembly)
HK1820L
Rear Extension Handle
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
SDS-MAXBullPoint(751423-A),BitGrease(194683-7),CleaningCloth(443122-7),D-StyleSideHandle(135283-4),PlasticCarryingCase(824882-4)
SDS-MAX Shank
• Anti-Vibration Technology (AVT
TM
) actively counteracts vibration of tool for greatly reduced
transmission to operator
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Variable Speed Dial allows operator to adjust speed based on materials or application
• No-Load Motor Suppression limits vibration and bit deflection when idling
• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement
• Slide Style On / Off Switch for easy continuous use applications
• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• LED Service Light indicates appropriate time to change carbon brushes
Constant Speed Control,
Variable Speed, Soft Start
27 Lbs. Demolition Hammer
SPECIFICATIONS
Bit Type
SDS-MAX
Blows Per Minute
950 - 1,900 BPM
Impact Energy
25.7 J (18.9 ft. lbs.)
AMPS (120V)
14.0 A
Overall Length
27-1/2˝ (700 mm)
Net Weight
27.1 lbs. (12.3 kg)
HM1214C
