Cordless
Power Tools
makita.ca
17
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
1/2˝ Square Drive,
Variable Speed, Reversible
High Torque To
Size / Weight Ratio
• Equipped with Flat Head Pin for improved socket
retention (DTW251XRFE, DTW251FX1, DTW251ZX1 Only)
• Compact and Lightweight Design (Only 6-1/2˝ Long)
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
1/2˝ Square
No Load Speed
0 - 2,100 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque 170 ft.lbs. (230 Nm)
Overall Length
6-1/2˝ (165 mm)
Net Weight
3.7 lbs (1.7 kg)
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830
(194205-3), Charger (DC18RC), Hook (324705-1),
Plastic Carrying Case (824753-5)
STANDARD EQUIPMENT INCLUDES:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3),
Hook (324705-1)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger
Sold Separately.
Hook (324705-1)
Round
Head Pin
Flat
Head Pin
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830
(194205-3), Charger (DC18RC), Hook (324705-1),
Plastic Carrying Case (824753-5)
STANDARD EQUIPMENT INCLUDES:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3),
Hook (324705-1)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger
Sold Separately.
Hook (324705-1)
1/2˝ Cordless Impact Wrenches
DTW253RFE
STANDARD EQUIPMENT INCLUDES:
DTW253RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8),
Plastic Carrying Case (824753-5)
DTW253F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3)
DTW253Z:
Tool Only. Batteries and Charger Sold Separately.
High Torque To Size / Weight Ratio
• Compact and Lightweight Design (Only 6-1/8˝ Long)
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3/8˝ Square Drive, Variable Speed,
Reversible
3/8˝ Cordless Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
3/8˝ Square
No Load Speed
0 - 2,300 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque 155 ft. lbs. (210 Nm)
Overall Length
6-1/8˝ (155 mm)
Net Weight
3.3 lbs (1.5 kg)
DTW253F
DTW253Z
LXWT01
STANDARD EQUIPMENT INCLUDES:
LXWT01:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Hook (345736-7), Battery Cover (450128-8),
Plastic Carrying Case (824777-1)
LXWT01Z:
ToolOnly.BatteriesandChargerSoldSeparately.
Hook(345736-7)
Compact and Lightweight Design with High Maximum Fastening Torque
• Features 7/16˝ One-Touch Bit Holder for rapid bit changes
• Heavy Duty Ring enables tool to be hung on hook or bucket
lines when not immediately in use
• Same Fastening Torque in forward and reverse rotation
• Rubber Joint Construction suppresses transmission of
vibration to battery, minimizing battery failures due to terminal breakage
or poor electrical contact
7/16˝ Cordless Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
7/16˝ Hex
No Load Speed
1,900 RPM
Impacts Per Minute
2,200 IPM
Maximum Torque
325 ft. lbs. (440 Nm)
Overall Length
10-3/4˝ (273 mm)
Net Weight
7.8 lbs. (3.5 kg)
7/16˝ Hex Drive,
Variable Speed,
Reversible
LXWT01Z
DTW251RFE
DTW251F
DTW251Z
DTW251XRFE
DTW251FX1
DTW251ZX1
DTW251RFE, DTW251F, DTW251Z, DTW251XRFE, DTW251FX1, DTW251ZX1
DFR550RFE
STANDARD EQUIPMENT INCLUDES:
DFR550RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), 2 Ea. Square Bit 2-162 (784645-9),
Phillips Bit 2-162 (784251-0), Belt Clip (281217-6), Plastic Carrying Case (824807-8)
DFR550Z:
ToolOnly.BatteriesandChargerSoldSeparately.
2Ea.SquareBit2-162(784645-9),PhillipsBit2-162(784251-0),BeltClip(281217-6)
High Torque Model For Driving Screws Up To 2-3/16˝ Long
• Anti-Tilt Mechanism prevents screws from swaying out of the drive position
• Silent Clutch enables smooth gearing engagement for quiet operation and reduced maintenance
• Adjustable Stopper Base can be set for different screw lengths
• Lock On Button for easy continuous operation
• Non-Marring Rubber Contact Tip prevents damage to materials
• Dust Proof Construction enables smooth sliding action of Stopper Base for more efficient operation
• Folding Screw Guide prevents collated screw strip from becoming tangled
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Reversible
1/4˝ Cordless Autofeed Screwdriver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ (6.5 mm)
Screw Capacity 1˝ - 2-3/16˝ (25 - 55 mm)
No Load Speed
4,000 RPM
Overall Length
16-3/4˝ (424 mm)
Net Weight
5.1 lbs (2.3 kg)
DFR550Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
2Ea.SquareBit2-182(784647-5),PhillipsBit2-182(784253-6),BeltClip(281217-6)
High Torque Model For Driving Screws Up To 2-15/16˝ Long
• Anti-Tilt Mechanism prevents screws from swaying out of the drive position
• Silent Clutch enables smooth gearing engagement for quiet operation and reduced maintenance
• Adjustable Stopper Base can be set for different screw lengths
• Lock On Button for easy continuous operation
• Non-Marring Rubber Contact Tip prevents damage to materials
• Dust Proof Construction enables smooth sliding action of Stopper Base for more efficient operation
• Folding Screw Guide prevents collated screw strip from becoming tangled
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Reversible
1/4˝ Cordless Autofeed Screwdriver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
Screw Capacity
1-3/4˝ to 2 - 15/16˝
(45 mm to 75 mm)
No Load Speed
4,000 RPM
Overall Length
18-1/4˝ (464 mm)
Net Weight
5.1 lbs. (2.3 kg)
DFR750Z
